Запчасти Case IH PUMA 185 (90.120.0102[03]) - DELUXE AIR SEAT WITH REELING SEAT BELT - BREAKDOWN (VAR.720963) (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case IH PUMA 185 - (90.120.0102[03]) - DELUXE AIR SEAT WITH REELING SEAT BELT - BREAKDOWN (VAR.720963) (90) - PLATFORM, CAB, BODYWORK AND DECALS
11
3
9
1
11
5
8
10
9
6
home
9
8
9
8
2
6
8
7
9
12
6
3
9
4
3
11
9
3
14
11
8
13

Артикул

Название

Примечание

Количество

1

84155767

SEAT

ASSY, See Also Page 01,02

1шт.

Electrohydraulic Remote Models Only

1шт.

1

84171082

DRIVER SEAT

ASSY, See Also Page 01,02

1шт.

Mechanical Remote Models Only

1шт.

2

87529810

SUSPENSION

Suspension ASSY

1шт.

3

82020847

KIT

Suspension Shock Absorber

1шт.

4

87529828

HOUSING

Lower Housing

1шт.

5

82020819

KIT

Air Spring

1шт.

6

82030804

KIT

Compressor W/Heating

1шт.

7

82020846

KIT

Suspension Scissors

1шт.

8

82020830

SERVICE KIT

Suspension Fore/Aft Damper

1шт.

9

82020845

SERVICE KIT

Bumper and Roller

1шт.

10

82020844

KIT

Upper Housing

1шт.

11

87529817

KIT

Air Line

1шт.

12

82020843

KIT

Suspension Boot

1шт.

13

82021020

SERVICE KIT

Fore/Aft Isolator

1шт.

14

87529792

HARNESS

1шт.

Выбрано товаров: 17
