(1.75.0[10]) - REAR ELECTRONIC REMOTE CONTROL VALVES AND SOLENOID VALVES

Запчасти Case IH PUMA 180 (1.75.0[10]) - REAR ELECTRONIC REMOTE CONTROL VALVES AND SOLENOID VALVES (06) - ELECTRICAL SYSTEMS

Схема запчастей Case IH PUMA 180 - (1.75.0[10]) - REAR ELECTRONIC REMOTE CONTROL VALVES AND SOLENOID VALVES (06) - ELECTRICAL SYSTEMS
3
1
1.82.7/01a
2
home
1.82.7/06a 01
1.82.7/05a 01
1.82.7/04a 01
1.82.7/b
1.82.7/01d
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

87737701

SOLENOID

2шт.

2

5190768

COIL ASSY.

2шт.

3

87330318

HYD VALVE SECTION

LH

1шт.

3

87330318R

REMAN-HYD VALVE

PUMA 165, PUMA 180, PUMA 195, PUMA 210 all SERIAL NUMBER Z*BE 40001 --> 50000 AND 60001 --> … (1/09-)

1шт.

3

87330318C

CORE-VALVE HYD

Return Number

1шт.

3

87325955

HYD VALVE SECTION

Main

1шт.

3

87325955R

REMAN-HYD VALVE

PUMA 165,PUMA 180,PUMA 195,PUMA 210 ,All SERIAL NUMBER Z*BE 40001 --> 50000 AND 60001 --> … (1/09-)

1шт.

3

87325955C

CORE-VALVE HYD

Return Number

1шт.

3

87330385

HYD VALVE SECTION

RH

1шт.

3

87330385R

REMAN-HYD VALVE

PUMA 165, PUMA 180, PUMA 195, PUMA 210 SERIAL NUMBER Z*BE 40001 --> 50000 AND 60001 --> … All(1/09)

1шт.

3

87330385C

CORE-VALVE HYD

Return Number

1шт.
