(55.410.01) - BRAKE SYSTEM AND CLUTCH PEDAL SWITCHES

Запчасти Case IH PUMA 170 (55.410.01) - BRAKE SYSTEM AND CLUTCH PEDAL SWITCHES (55) - ELECTRICAL SYSTEMS

Схема запчастей Case IH PUMA 170 - (55.410.01) - BRAKE SYSTEM AND CLUTCH PEDAL SWITCHES (55) - ELECTRICAL SYSTEMS
1
18.100.03
3
2
33.202.0301 01a
4
2
33.202.03 01
5
1
1
6
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

82026949

PUSH BUTTON SWITCH

4шт.

2

83963569

CAPTIVE WASHER SCREW,Pan Hd, M4 x 12mm, Cl 4.8

6шт.

3

87605245

POTENTIOMETER,4000 Ohm, 13.5 VDC

Rotary Position Sensor

1шт.

4

84224890

BOLT,Hex, M5 x 30mm, Cl 8.8

2шт.

5

13272217

SCREW,Pozidriv Pan Hd, M4 x 16mm, Cl 5.8, Full Thd

2шт.

6

84193288

WASHER,4.3mm ID x 9mm OD x 0.8mm Thk

2шт.

Выбрано товаров: 6
