Запчасти Case IH PUMA 160 (90.102.03) - PNEUMATIC TRAILER BRAKE (UNIVERSAL) - ENGINE GUARDS (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case IH PUMA 160 - (90.102.03) - PNEUMATIC TRAILER BRAKE (UNIVERSAL) - ENGINE GUARDS (90) - PLATFORM, CAB, BODYWORK AND DECALS
1
2
3
6
6
10.001.01
5
4
home
7
7

Артикул

Название

Примечание

Количество

1

84273493

GUARD

A/C Compressor

1шт.

2

87590016

GUARD

Alternator

1шт.

3

87590024

SHIELD

Heat, Starter Motor

1шт.

4

87541648

GUARD

1шт.

5

87477900

GUARD

1шт.

6

14496501

WASHER,8.4mm ID x 17mm OD x 1.6mm Thk

10шт.

7

16043224

BOLT,Hex, M8 x 16mm, Cl 8.8

8шт.

7

16043624

SCREW,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd

2шт.

Выбрано товаров: 8
