(33.204.06) - VAR - 743700, 330427, 330430, 333648, 334648 - FRONT AXLE - BRAKE LINES

Запчасти Case IH PUMA 160 (33.204.06) - VAR - 743700, 330427, 330430, 333648, 334648 - FRONT AXLE - BRAKE LINES (33) - BRAKES & CONTROLS

Схема запчастей Case IH PUMA 160 - (33.204.06) - VAR - 743700, 330427, 330430, 333648, 334648 - FRONT AXLE - BRAKE LINES (33) - BRAKES & CONTROLS
21.113.01
1
21.111.01
2
3
home
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

87519145

PIPE

w/Bracket

1шт.

2

374888

BOLT,Hex, M16 x 2 x 25mm, Cl 8.8, Full Thd

1шт.

3

10520205

WASHER,Flat, 16.40mm ID x 28.00mm OD x 3.00mm, CST, ZND

1шт.

Выбрано товаров: 3
