Запчасти Case IH PUMA 130 (90.118.05[01]) - VAR - 330827, 331827, 743710 - TELESCOPIC, HEATED AND WITH REMOTE ADJUSTMENT REAR-VIEW MIRRORS - C9027 (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case IH PUMA 130 - (90.118.05[01]) - VAR - 330827, 331827, 743710 - TELESCOPIC, HEATED AND WITH REMOTE ADJUSTMENT REAR-VIEW MIRRORS - C9027 (90) - PLATFORM, CAB, BODYWORK AND DECALS
5
8
2
4
1
home
7
6
3

Артикул

Название

Примечание

Количество

1

87316908

RH MIRROR,238mm x 328mm

RH, Incl 5, 6 and 7

1шт.

1

87316907

LH MIRROR

LH, Incl 5, 6 and 7

1шт.

2

87346605

ARM

LH, Incl 8

1шт.

2

84398576

ARM

RH, Incl 8

1шт.

3

12577211

LOCK NUT,M10 x 1.5mm Pitch, 12.30mm High, Cl 8, ZND

4шт.

4

81869630

HEX SOC SCREW,M10 x 35mm, Cl 8.8

4шт.

5

87578865

COVER

LH

1шт.

5

87531075

COVER

RH

1шт.

6

87706600

MIRROR

2шт.

7

87017604

SELF-TAP SCREW,Phillips Drive, Pan HD, M3.5 x 1.3 x 13mm

4шт.

8

87365131

KNOB

2шт.

Выбрано товаров: 11
