Запчасти Case IH PUMA 130 (90.116.07) - VAR - 330518, 330519, 743707, 743708 - WIDE REAR FENDERS - DEFLECTOR (90) - PLATFORM, CAB, BODYWORK AND DECALS

1

84370541

GUARD

LH

1шт.

2

84367500

DEFLECTOR

RH

1шт.

3

10523401

WASHER,6.15mm ID x 18mm OD x 2mm Thk

6шт.

4

120100

BOLT,M6 x 20mm, Cl 8.8

3шт.

5

12574211

NUT,M6 x 1, Cl 8

4шт.

6

86624184

WASHER,9mm ID x 16mm OD x 1.6mm Thk

3шт.

7

14047317

NUT,M8 x 1.25

3шт.

8

86624182

WASHER,6.6mm ID x 18mm OD x 1.6mm Thk

1шт.

9

87520691

FENDER EXTENSION

LH, VAR 330519

1шт.

9

87520692

FENDER EXTENSION

RH, VAR 330519

1шт.

10

87622826

SPRING CLIP,0.5mm Thk

VAR 330519

8шт.

11

14188971

CLIP

VAR 330519

2шт.

12

82880745

SCREW,Phillips Drive, Pan HD, M4 x 16mm, Cl 4.8

VAR 330519

2шт.

13

10519201

WASHER,4.3mm ID x 9mm OD x 0.8mm Thk

VAR 330519

2шт.

14

84417110

DEFLECTOR

RH

1шт.
