Запчасти Case IH PUMA 125 (1.29.7[02]) - SEMI POWER SHIFT - TRANSMISSION LUBRICATION SYSTEM - PIPES (03) - TRANSMISSION

1

87570548

BLOCK

ASSY

1шт.

2

10119311

PLUG,M16 x 1.5 x 12, Cl5.8

1шт.

3

14437885

O-RING,13.30mm ID x 2.40mm

1шт.

4

86579675

HYD CONNECTOR,13/16"-16 ORFS x M16 x 1.5 ORB

M16x1.5, 13/16"-16

2шт.

5

81845038

O-RING,0.5" ID x 0.07" Thk

2шт.

6

82019812

SEAL,13.8mm ID x 8.9mm OD x 1.5mm Thk

2шт.

7

86579676

HYD CONNECTOR,13/16" - 16 ORFS x M18 x 1.5 ORB

1шт.

8

86598101

O-RING,2.2mm Thk x 15.3mm ID, Cl 6, 90 Duro

1шт.

9

9992298

O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro

1шт.

10

5135738

O-RING,0.103" Thk x 0.674" ID, -115, 80 Duro

1шт.

11

5167639

SEALING WASHER,13.4mm ID x 24mm OD x 1.5mm Thk

D=16

1шт.

12

87519177

BANJO BOLT,M16 x 1 x 115mm

1шт.

13

87519175

HOSE,9.5mm ID x 800mm L, SAE 100R16

Lube Cylinder

2шт.

14

5185052

90 ELBOW,13/16"-16 x M18 x 1.5

13/16"-16, M18x1.5

2шт.

15

5185511

O-RING,1.78mm Thk x 12.42mm ID, 85 Duro

12.42x1.78

2шт.

16

14437985

O-RING,15.3mm ID x 2.4mm

2шт.
