Артикул
Название
Примечание
Количество
A222-564
TEE - 3/8" #84LB hi-duty (for A20106, A20107 and A20109 tubes)
1шт.
A8108
BRACE - hood rear support plate
1шт.
3/8" x 1" N.F. hex. bolt w/nut and lockwasher
1шт.
A10118
LUBE NIPPLE
POST - fuel tank rear support, L.H.
1шт.
1/2" x 1" N.C. nylock hex. bolt w/lockwasher
2шт.
A11358
PLATE - hood rear support
1шт.
A11361
TANK - fuel, with valves and gauge assembly
1шт.
A11362
ANGLE - fuel tank front support
1шт.
3/8" x 1" N.F. hex. bolt w/hex. nut and lockwasher
3шт.
A11363
ANGLE - fuel tank bottom support
1шт.
1/2" x 1-1/4" N.F. hex. bolt
3шт.
1/2" N.F. hex. nut w/lockwasher
2шт.
A11364
SHEET - fuel tank side
4шт.
1/4" x 5/8" N.C. truss hd. mach. screw w/nut and lockwasher
4шт.
1/4" x 1/2" N.C. truss hd. mach. screw w/lockwasher
4шт.
A11901
BRACKET - fuel tank side sheet
4шт.
1/4" x 3/4" N.F. hex. bolt w/nut and lockwasher
4шт.
A20106
TUBE - vapor outlet valve to tee w/nut
1шт.
A20107
TUBE - liquid outlet valve w/nut
1шт.
A20109
TUBE - tee to fuel filter
1шт.
A20423
GAUGE - visible fuel
1шт.
1/4" x 15/16" N.F. rhd. mach. screw (zinc plated) w/lockwasher
4шт.
A20489
GASKET - visible fuel gauge mounting
1шт.
A20696
SEAL
VALVE - safety relief
1шт.
A20697
WIPER
CAP - safety relief valve
1шт.
4003AA
X
VALVE - liquid and vapor outlet
2шт.
4008AA
GAUGE - fixed liquid level
1шт.
4022AA
STRAP - fuel tank, and "T" bolt
2шт.
4323AA
VALVE - double check filler
1шт.
O6112AB
POST - fuel tank rear support, R.H.
1шт.
1/2" x 1" N.C. nylock hex. bolt w/lockwasher
2шт.
1/2" x 1-1/4" N.F. hex. bolt w/nut and lockwasher
1шт.
O7653AB
LOOM - tee to filter tube (A20109)
1шт.
O7659AB
LOOM - vapor valve to tee tube (A20106)
1шт.
O8333AB
GROMMET - rubber, hood rear support plate
2шт.
O8830AB
CRADLE - fuel tank
2шт.
1/2" x 1-1/2" N.F. hex. bolt w/nut and lockwasher
2шт.
O8840AB
LOOM - liquid valve to tee tube (A20107)
1шт.
Выбрано товаров: 39
