Артикул
Название
Примечание
Количество
A222-42
ELBOW - #69FL, 1/4" tube and 1/8" P.T., Serial Range: A20691-A20637
1шт.
A222-72
TEE - #72FL, 1/4" tube x 1/8" P.T., for injector leak-off tubes
6шт.
A8013
NOZZLE INJECTION
NOZZLE - injector, w/holder and gasket
6шт.
A10678
STUD
- nozzle holder, large
6шт.
A10679
GASKET
- for A10678 stud
6шт.
A20162
TUBE
- injector leak-off, upper
2шт.
A20501
TUBE
- fuel injector, w/sleeves and nuts, no. 1 cylinder
1шт.
A20502
TUBE
- fuel injector, w/sleeves and nuts, no. 2 cylinder
1шт.
A20503
TUBE
- fuel injector, w/sleeves and nuts, no. 3 cylinder
1шт.
A20504
TUBE
- fuel injector, w/sleeves and nuts, no. 4 cylinder
1шт.
A20505
TUBE
- fuel injector, w/sleeves and nuts, no. 5 cylinder
1шт.
A20506
TUBE
- fuel injector, w/sleeves and nuts, no. 6 cylinder
1шт.
A20508
CLAMP
- injector tube (2 tubes)
2шт.
#10 x 1" N.C. rhd. mach. screw w/nut and lockwasher
2шт.
A20509
CUSHION
- between A20508 clamp and injector tubes
2шт.
A20541
CLIP
- for A22186 leak-off tube
1шт.
A20691
TUBE - injector leak-off to relief valve
1шт.
A22186
TUBE
- fuel pump leak-off to #1 cylinder
1шт.
O9845AB
X
NOZZLE - injector w/09847AB gasket
6шт.
O9847AB
X
GASKET - injector nozzle
6шт.
O9848AB
X
STUD - nozzle holder, small
6шт.
3/8" N.F. hex. nut
6шт.
O9967AB
X
SLEEVE - fuel injector tube coupling
12шт.
O9968AB
NUT - fuel injector tube coupling
12шт.
O9969AB
X
CLAMP - injector tube (3 tubes)
4шт.
#10 x 1" N.C. rhd. mach. screw w/hex. nut and lockwasher
4шт.
O9970AB
X
CLAMP - injector tube (5 tubes)
2шт.
#10 x 1" N.C. rhd. mach. screw w/hex. nut and lockwasher
2шт.
O9972AB
X
CUSHION - for 09969AB clamp
4шт.
O9973AB
X
CUSHION - for 09970AB clamp
2шт.
O9978AB
X
TUBE - injector leak-off, lower
3шт.
O10604AB
X
CHECK VALVE - fuel pump leak-off
1шт.
O10618AB
X
GASKET - injector pressure adjusting screw protective cap
6шт.
222-102
SLEEVE,1/4" Tube
#60FL for A20162, A20691, A22186 and 09978AB tubes (Replaces A222-102), sleeves and nuts for fuel tubes 1/4" Tube
1шт.
87017024
TUBE NUT,1/2"-24
NUT - #61FL (1/4") for A20162, A20691, A22186 and 09978AB tubes (Replaces A222-112), sleeves and nuts for fuel tubes
1шт.
Выбрано товаров: 35
