Запчасти Case IH 930 (4-12) - SPARK IGNITION ENGINE, AIR CLEANER, PAGE 33 (02) - ENGINE

A11830

SUPPORT - air cleaner (to cylinder block)

2шт.

A21433

CAP

PRE-SCREENER - air intake (standard equipment) (see A22301)

1шт.

A22301

PRESCREENER

PRE-SCREENER - air intake (special equipment for severe operating conditions where extreme chaff conditions are found)

1шт.

O9820AB

STRAP - air cleaner (to A11830)

2шт.

A22780

SPRING

- screen attaching

2шт.

A22781

CLIP

- spring attaching

1шт.

A22782

SCREEN

ASSEMBLY (includes springs and clip)

1шт.

1

A7621

INSERT - distributor support, ignition

1шт.

2

A7622

CLAMP - distributor mounting, ignition

1шт.

3

13-516

BOLT,Hex, 5/16" - 18 x 1", Gr 5

Distributor ignition Hex, 5/16"-18 x 1", G5, Full Thd

1шт.

4

75-520

SCREW - 5/16" x 1-1/4" N.C. rhd. machine, distributor ignition

1шт.

5

92-5

LOCK WASHER,5/16"

distributor ignition 5/16"

2шт.

6

A7623

O-RING,0.139" Thk x 0.984" ID, -214, Cl 5, 75 Duro

"O" RING - distributor support insert, ignition

1шт.

7

A7625

COVER - magneto bracket opening, distributor ignition

1шт.

8

13-620

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5, Full Thd

Distributor ignition Hex, 3/8"-16 x 1 1/4", G5, Full Thd

3шт.

9

92-6

LOCK WASHER,3/8"

distributor ignition 3/8"

3шт.

10

A7922

CLIP

- for distributor wire on cylinder block, distributor ignition

1шт.

11

A20143

ELECTRICAL WIRE

WIRE - spark plug, #2 and #3 cylinders (15"), distributor ignition

2шт.

12

A20144

ELECTRICAL WIRE

WIRE - spark plug, #4 and #5 cylinders (11"), distributor ignition

2шт.

13

A20265

RING - spark plug wire (3 wire), distributor ignition

1шт.

14

A20905

SPARK PLUG

PLUG - spark, 18MM (Champion #D9) (includes 07769AB gasket), distributor ignition

6шт.

15

A20934

X

RESISTOR (WICO no. X30061B), distributor ignition

1шт.

16

14-512

BOLT,Hex, 5/16" - 24 x 3/4", Gr 5, Full Thd

Distributor ignition Hex, 5/16"-24 x 3/4", G5, Full Thd

1шт.

17

25-115

NUT,5/16"-24, G5

- hex (5/16"-24 NF), distributor ignition

1шт.

18

92-5

LOCK WASHER,5/16"

distributor ignition 5/16"

1шт.

19

A20949

X

COIL - ignition (Wico no. X30081B), distributor

1шт.

20

75-510

HANDBOOK

SCREW - 5/16" x 5/8" N.C. rhd., distributor ignition

2шт.

21

193-45

WASHER,Ext-Int Tooth, 5/16"

- 5/16" shakeproof ext.-int. #4018-24, distributor ignition

2шт.

22

A21164

DISTRIBUTOR (Wico no. X30174), distributor ignition

1шт.

23

A21820

X

NIPPLE - ignition coil wire, distributor

1шт.

24

A22879

WIRE - resistor to ignition coil (serial no. 8172001 and after) (see 010224AB), distributor

1шт.

25

O1798AB

RING - spark plug wire (6 wires), distributor ignition

1шт.

26

O4024AB

X

WIRE - spark plug, #1 cylinder (25-1/2"), distributor ignition

1шт.

27

O4492AB

X

WIRE - spark plug, #6 cylinder (21-1/2"), distributor ignition

1шт.

28

O5051AB

WIRE - starter solenoid to resistor (prior to serial no. 8172001), distributor ignition

1шт.

29

O7769AB

X

GASKET - spark plug, distributor ignition

6шт.

30

O8861AB

X

"O" RING - drive bracket cover, distributor ignition

1шт.

31

O10224AB

WIRE - resistor to coil and coil to distributor (prior to serial no. 8172001), distributor ignition

2шт.

31

O10224AB

WIRE - coil to distributor (serial no. 8172001 and after) (see A22879), ignition

1шт.

32

VT2876

X

WIRE - center coil terminal to center distributor cap terminal, distributor ignition

1шт.

33

VT3561

X

NIPPLE - distributor to coil and spark plug wires, distributor ignition

7шт.

217-3

ADAPTER - 1/4" male to 3/8" female in 1/4" pipe tee at block, regulator (Figure 42)

1шт.

O9739AB

X

VALVE - water drain, regulator (Figure 42)

1шт.

A20541

CLIP

- choke control (on air cleaner clamp), carburetor (Figure 42)

1шт.
