Запчасти Case IH 930 (2-026[2]) - LP-GAS ENGINE, VALVE GRIND GASKET KIT (02) - ENGINE

A7526

OIL SEAL

RING - piston, top

6шт.

A7527

OIL SEAL

RING - piston, second and third

12шт.

A8090

RING

S - piston, set of (24) Perfet Circle 2-in-1 chrome

1шт.

A8656

RING

- piston, oil

6шт.

A11110

X

SLEEVE - cylinder

6шт.

A20393

LINING

LINERS - connecting rod bearing, top and bottom half (std. size)

6шт.

A21515

X

PISTON (see A22192)

6шт.

A21721

BUSHING

S - piston pin, set of (2) 09716AB

3шт.

A21723

PIN

PISTON PINS - set of (2) 09713AB and (4) 09714AB retainers

3шт.

A22192

SET OF 2 CYLINDER SLEEVES, pistons, rings and piston pins

3шт.

4603AA

X

ROD - connecting, with cap, bushing and capscrew

6шт.

O9712AB

X

"O" RING - cylinder sleeve

12шт.

O9713AB

PIN - piston (use A21723)

1шт.

O9714AB

X

RING - piston pin retainer (use A21723)

1шт.

O9716AB

BUSHING - piston pin (use A21721)

1шт.

O9718AB

X

CAPSCREW - connecting rod

12шт.

A7182

KIT

LINERS - crankshaft bearing (wide-upper and lower) (.002" undersize)

4шт.

A7188

BEARING LINER

LINERS - crankshaft bearing (wide-upper and lower) (.010" undersize)

4шт.

A7194

KIT

LINERS - crankshaft bearing (wide-upper and lower) (.020" undersize)

4шт.

A7200

KIT

LINERS - crankshaft bearing (wide-upper and lower) (.030" undersize)

4шт.

A7204

WASHER

- crankshaft thrust (.006" oversize) (see 09705AB)

2шт.

A9871

FLYWHEEL - (use A20880)

1шт.

A20394

LINING

LINERS - crankshaft bearing (narrow-upper and lower) (std. size)

3шт.

A20579

LINING

LINERS - crankshaft bearing (narrow-upper and lower) (.002" undersize)

3шт.

A20582

LINING

LINERS - crankshaft bearing (narrow-upper and lower) (.010" undersize)

3шт.

A20585

KIT

LINERS - crankshaft bearing (narrow-upper and lower) (.020" undersize

3шт.

A20588

KIT

LINERS - crankshaft bearing (narrow-upper and lower) (.030" undersize)

3шт.

A20875

GEAR, RING

GEAR - flywheel ring

1шт.

A20880

FLYWHEEL - w/ring gear

1шт.

B138-71

ROLL PIN - 5/32" x 5/8", for 09832AB wiggle pin

1шт.

6301A

CAP - crankshaft bearing, wide

3шт.

A6302A

X

CAP - crankshaft bearing, narrow

3шт.

6303A

CAP - crankshaft thrust bearing

1шт.

4706AA

X

LINERS - crankshaft bearing (wide-upper and lower) (std. size)

4шт.

O8651AB

X

KEY - for crankshaft gear and lower drive pulley

2шт.

O9700AB

CRANKSHAFT

1шт.

5/8" x 3" N.F. hex. bolt w/lockwasher

4шт.

O9705AB

X

WASHER - crankshaft thrust (std. size) (see A7204)

2шт.

O9706AB

SCREW - crankshaft bearing cap

14шт.

O9707AB

X

GEAR - crankshaft

1шт.

O9708AB

X

OIL SEAL - crankshaft, front

1шт.

O9829AB

BOLT - flywheel dowel

2шт.

5/8" std. lockwasher

2шт.

O9831AB

X

PLUG - flywheel oil control

1шт.

O9832AB

PIN - wiggle, flywheel oil control plug

1шт.

A22347

KIT

GASKET KIT, valve grind, includes the following:

1шт.

A7363

MANIFOLD GASKET

intake manifold

3шт.

A7669

RING

rubber, cylinder head gasket

6шт.

A11421

GASKET

thermostat housing

1шт.

A11423

SEAL

"O" RING, thermostat seal

1шт.

A21517

CYLINDER HEAD GASKET

cylinder head

3шт.

O8569AB

X

"O" RING, cylinder head oil passage

3шт.

O9570AB

X

GASKET, Serial Range: carburetor-manifold

1шт.

O9772AB

X

"O" RING, valve rocker arm shaft tube

3шт.

O9804AB1

X

GASKET, water manifold

6шт.

O9815AB

X

GASKET, exhaust manifold

6шт.

O9959AB

X

GASKET, cylinder head cover

3шт.
