Запчасти Case IH 920 (18) - HEAVY DUTY SWINGING DRAW BAR WITH CLEVIS END (09) - CHASSIS

5949A

YOKE - draw bar (use 3526AA)

1шт.

O6087AB

X

BOLT - draw bar pivot

2шт.

O6134AB

BUSHING - front, draw bar channel

2шт.

3/4" x 2-1/2" hex. head cap screw, N.C. thread

2шт.

3/4" standard lockwasher

2шт.

O6135AB

BUSHING - rear, draw bar channel

2шт.

3/4" x 3" hex. head cap screw, N.C. thread

2шт.

3/4" standard lockwasher

2шт.

O6396AB

CLIP - draw bar pivot bolt

1шт.

O7969AB

PIN - draw bar guide

1шт.

A2425AA

BRACKET - draw bar pivot, with plate

1шт.

5/8" x 2-1/2" hex. head cap screw, N.F. thread

2шт.

5/8" hex light nut. N.F. thread

2шт.

5/8" standard lockwasher

2шт.

3525AA

ANGLE - draw bar guide

1шт.

3526AA

DRAW BAR - with yoke

1шт.
