Запчасти Case IH 920 (24[1]) - HYDRAULIC POWER STEERING PUMP USE PAGE 100 OF PARTS CATALOG NO. 628 WITH THE FOLLOWING EXCEPTIONS (08) - HYDRAULICS

When replacing A10057 rotor type pump with the new style roll pump A20375, order 1 - A20375 pump, 1 - A20401 strap, 1 - A20403 hose and 1 - A20375 pump, 1 - A20401 strap, 1 - A20403 hose and 1 - A20404 hose as a replacement for A8188 strap, A10057 pump and A10058 hose.

1шт.

A20375

PUMP - hydraulic power steering (roll type) w/return, Serial Range: hose-reservoir

1шт.

A20401

STRAP - pump mounting (use with A20375 pump)

1шт.

3/8" fin. hex. nut w/lockwasher

1шт.

7/16" x 1-1/2" fin. hex. bolt w/lockwasher (LP-gas only)

2шт.

A20608

HOSE - pump to valve (pressure) use with A20375 pump

1шт.

A20609

HOSE - valve to pump reservoir (return) use with A20375 pump

1шт.

5/8" hose clamp

1шт.
