Запчасти Case IH 900 (096) - STEEL REAR WHEELS, 54 INCH X 11-1/8 INCH (06) - POWER TRAIN

Схема запчастей Case IH 900 - (096) - STEEL REAR WHEELS, 54 INCH X 11-1/8 INCH (06) - POWER TRAIN

Артикул

Название

Примечание

Количество

A11939

WHEEL - rear, steel (11-1/8" x 54")

2шт.

A7105M

EXTENSION - rear wheel (54" x 8") machy. item

2шт.

O1959AB

STRAP - tie, rear wheel extension

14шт.

3/4" x 1-3/4" mach. bolt w/hex. nut and lockwasher (tie strap to extension)

14шт.

3/4" x 2" mach. bolt w/hex. nut and lockwasher (tie strap to rear wheel)

14шт.

3/4" x 2" no. 1 keyhead old standard plow bolt w/hex. and lockwasher (tie strap to extension)

14шт.

A7365M

EXTENSION - rear wheel (54" x 12") machy. item, steel

2шт.

O1959AB

STRAP - tie, rear wheel extension, steel, (54" x 12")

14шт.

3/4" x 1-3/4" mach. bolt w/hex. nut and lockwasher (tie strap to extension), steel rear wheel, (54" x 12")

14шт.

3/4" x 2" no. 1 key head old standard plow bolt w/hex. nut and lockwasher, steel rear wheel extensions, (54" x 12")

14шт.

489AA

LUGS - set of (56) steel spade, for rear wheel (machy. item) consists of: 56 - 02802AB lugs, bolts, nuts and lockwashers

1шт.

557AA

LUGS - set of (28) steel spade, for rear wheel extensions (machy. item) consists of: 28 - 02802AB lugs, bolts, nuts and lockwashers

1шт.

O2802AB

LUG - 6" steel spade for rear wheels (see 489AA)

56шт.

3/4" x 1-1/2" mach. bolt w/hex. nut and lockwasher, lugs for rear wheels

112шт.

O2802AB

LUG - 6" steel spade, for rear wheel extensions (see 557AA)

28шт.

3/4" x 1-1/2" mach. bolt w/hex. nut and lockwasher, lugs for rear wheels

42шт.

3/4" x 2" mach. bolt w/hex. nut and lockwasher, lugs for rear wheels

14шт.

Выбрано товаров: 17
