Запчасти Case IH 886 (02-01) - MISCELLANEOUS, SERVICE PACKAGES AND ASSORTED GASKETS Accessories & Attachments / Miscellaneous

371418R91

PACKAGE

front wheel bearing overhaul, consists of

1шт.

G15215

ROLLER BEARING

BEARING ASSY, front wheel inner cone

1шт.

619387R1

BEARING CUP

BEARING, front wheel inner cup

1шт.

618023R91

BEARING ASSY,34.93mm ID x 18.2mm W

BEARING ASSY, front wheel outer cone

1шт.

618024R1

BEARING CUP,65.113mm OD x 13.97mm W

Front wheel outer

1шт.

369860R1

GASKET,0.79mm Thk

front wheel hub cap

1шт.

370254R91

OIL SEAL,57.02mm ID x 82.55mm OD x 6.86mm Thk

ASSY, front wheel oil

1шт.

48703D

RETAINER

front wheel oil seal

1шт.

386682R97

O-RING PACKAGE, chassis overhaul, consists of

1шт.

352221R1

O-RING,0.103" Thk x 0.549" ID, -113, Cl 5, 75 Duro

9/16 x 3/4 x 3/32 cam pivot and selector drive

2шт.

252483R1

O-RING,-218, 70 Duro, 1.234" ID x .139" Thk

1-1/4 x 1-1/2 x 1/8 clutch housing suction tube

2шт.

707253R1

O-RING,-222, 70 Duro, 1.484" ID x .139" Thk

1-1/2 x 1-3/4 x 1/8 clutch hsg suction tube

1шт.

264681R1

O-RING,0.139" Thk x 6.48" ID, -260, Cl 5, 75 Duro

6-1/2 x 6-3/4 x 1/8 rear axle cap seal

2шт.

381884R1

O-RING,0.103" Thk x 0.987" ID, -120, Cl 6, 90 Duro

1 x 1-3/16 x 3/32 cover to seat support, small

3шт.

386867R1

O-RING,0.103" Thk x 1.11" ID, -122, Cl 6, 90 Duro

1-1/8 x 1-5/16 x 3/32 cover to seat support

1шт.

384377R1

O-RING,0.103" Thk x 2.55" ID, -141, Cl 6, 90 Duro

2-5/16 x 2-1/2 x 3/32 cover to seat support, large

1шт.

360610R1

O-RING,1.609" ID x 0.139" Width

1-5/8 x 1-7/8 x 1/8 hydraulic filter suction tube

1шт.

293726R1

O-RING,0.139" Thk x 2.234" ID, -228, Cl 5, 75 Duro

2-1/4 x 1/8 hyd filter suction tube

1шт.

382997R1

O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro

1/2 x 5/8 x 1/16 park lock actuating shaft

1шт.

352221R1

O-RING,0.103" Thk x 0.549" ID, -113, Cl 5, 75 Duro

9/16 x 3/4 x 3/32 cam pivot shaft

1шт.

355966R1

O-RING,0.424" ID x 0.103" Width

7/16 x 5/8 x 3/32 reverse shift pivot arm shaft

1шт.

385744R1

SEALING RING

rear frame pressure port oil

2шт.

388306R1

RING,32.77mm ID x 39.12mm OD x 3.17mm Thk

SEAL, rear frame pressure port oil

1шт.

387926R2

RING

O-RING, seal, draft control port cover

2шт.

128359

O-RING,0.07" Thk x 0.614" ID, -16, Cl 5, 75 Duro

5/8 x 3/4 x 1/16, rear frame cover shift shaft

2шт.

529133R1

RING

rear axle carrier cap sealing

2шт.

386683R95

GASKET

PACKAGE, chassis overhaul gasket, consists of

1шт.

380067R4

GASKET

CLUTCH HOUSING GASKET

1шт.

384078R1

GASKET

CLUTCH HOUSING BOTTOM COVER GASKET

1шт.

380112R1

GASKET

CLUTCH HOUSING COVER GASKET

1шт.

383330R1

GASKET

DRAFT CONTROL ADJ OPENING COVER GASKET

1шт.

385757R2

GASKET

DRIVE ATT OPENING COVER GASKET

1шт.

369860R1

GASKET,0.79mm Thk

FRONT WHEEL HUB GASKET

2шт.

23977DB

GASKET

FUEL TANK FILLER CAP GASKET

1шт.

381467R1

GASKET

INDEPENDENT PTO OPENING COVER GASKET

1шт.

382257R2

GASKET

OIL FILTER COVER GASKET

1шт.

382244R4

GASKET

PUMP OPENING COVER GASKET

1шт.

380225R1

GASKET

REAR AXLE CARRIER GASKET

2шт.

380264R2

GASKET

REAR FRAME COVER GASKET

1шт.

380315R1

GASKET

REAR FRAME FRONT COVER GASKET

1шт.

382416R1

GASKET

VALVE ADJ OPENING COVER GASKET

1шт.

1267295C91

KIT

PACKAGE, product graphics, replaces 120232C99, consists of upper instrument panel w/TA (NSS), upper instrument panel w/o TA (NSS), lower instrument panel (NSS), International stripe LH (NSS)

1шт.

(2) 786 model designation (NSS), (2) 886 model designation (NSS), (2) 986 model designation (NSS), (2) 1086 model designation (NSS), (2) 1486 model designation (NSS), (2) 1586 model designation (NSS), (1) stripe front LH

1шт.

111480C3

DECAL

CAUTION INSTRUCTIONS

1шт.

120391C1

DECAL

CAUTION INSTRUCTIONS

1шт.

64553C2

PRODUCT GRAPHIC

CAUTION INSTRUCTIONS IPTO

1шт.

70571C1

DECAL

CAUTION INSTRUCTIONS ROPS

1шт.

(1) air conditioning instructions (NSS), (1) hydraulic filter instructions (NSS), (1) hydraulic filter warning (NSS), (1) hydraulic seat adjusting (NSS), (1) digital tachometer (NSS), (1) digital tachometer (NSS), (1) digital tachometer (NSS), (1) digital tachometer (NSS), (1) upper instrument panel (NSS), (1) upper instrument panel (NSS), (1) lube chart (NSS), (1) important, metric

1шт.

71656C92

PACKAGE

PRODUCT GRAPHICS, cab trim, consists of (1) qtr. panel trim top (NSS), (1) qtr. panel trim LH (NSS), (1) qtr. panel trim RH (NSS)

1шт.

120397C1

EMBLEM CASE/IH

PRODUCT GRAPHIC, IH emblem

1шт.

2751846R1

EMBLEM CASE/IH

PRODUCT GRAPHIC, IH emblem

1шт.

145195

SCREW, 10-16 x 5/8 C-Z slt-pan-hd tap

2шт.

142862

SCREW,Type U Metallic, Rnd Hd, #4 x 1/4"

4 x 1/4 rd-hd blunt metal drive, serial no. plate mtg.

2шт.

131151C1

PRODUCT GRAPHIC

digital data gage, metric display, 886, 986 and 1086 tractors

1шт.

131152C1

PRODUCT GRAPHIC

difital data gage, metric display, 1486 tractor

1шт.

77583C91

PACKAGE

IH trademark, large size, consists of (2) IH trademark 6.58 x 7.09 (NSS), (2) IH trademark 7.68 x 8.27 (NSS), (2) IH trademark 10.24 x 11.02 (NSS)

1шт.

77582C91

PACKAGE

IH trademark, medium size, consists of (2) IH trademark 3.66 x 3.94 (NSS), (2) IH trademark 4.39 x 4.72 (NSS) (2) IH trademark 5.48 x 5.91 (NSS)

1шт.

77581C91

PRODUCT GRAPHIC

PACKAGE, IH trademark, small size, consists of (2) IH trademark 1.46 x 1.57 (NSS), (2) IH trademark 2.19 x 2.36 (NSS) (2) IH trademark 2.93 x 3.15 (NSS)

1шт.

547495R92

DECAL KIT

PACKAGE, International, for red machines, consists of (2) International 8.56 x .56 (NSS), (2) International 14.06 x .94 (NSS), (2) International 23.12 x 1.50 (NSS), (2) International 35.12 x 2.25 (NSS)

1шт.

547497R92

DECAL

PACKAGE, model designation, for red machines, consists of (2) model designation 8.78 x 2.45 (NSS), (2) model designation 14.08 x 4.50 (NSS), (2) model designation 20.04 x 7.57 (NSS), (2) model designation 15.20 x 7.56 (NSS)

1шт.

547496R92

DECAL

PACKAGE, International, for yellow machines, consists of (2) International 8.50 x .50 (NSS), (2) International 17.00 x 1.00 (NSS), (2) International 17.00 x 1.00 (NSS), (2) International 23.00 x 1.38 (NSS), (2) International 35.00 x 2.12 (NSS)

1шт.

547498R92

DECAL

PACKAGE, model designation, for yellow machines, consists of (2) model designation 12.20 x 3.00 (NSS), (2) model designation 15.80 x 4.68 (NSS)

1шт.
