Запчасти Case IH 886 (08-15) - ELECTRICAL, CLIPS AND GROMMETS (06) - ELECTRICAL

Схема запчастей Case IH 886 - (08-15) - ELECTRICAL, CLIPS AND GROMMETS (06) - ELECTRICAL
5
4
1
3
2
7
6

Артикул

Название

Примечание

Количество

1

365584R1

CLIP

7 pole connector cables, 5/8, 1, 1, 13/32, (I)

2шт.

179833

BOLT,Hex, 3/8" - 16 x 1/2", Gr 5, Full Thd

1шт.

95-11041

WASHER,3/8"

(13/32 x 13/16 x .051) 3/8"

1шт.

1

370383R1

CLIP

solenoid switch cables, 3/4, 15/16, 1-3/4, 15/32, (I)

2шт.

102635

NUT,3/8"-16, G5

1шт.

2

365524R1

CLAMP

CLIP, key switch cable

1шт.

2

146422C1

CLAMP

CLIP, battery cable, long, 3/4, 15/16, 2-5/8, 13/16, (I) replaces 120421C1

1шт.

3

363660R1

CLIP

main harness, twisted, 3/4, 3/4, 2-5/8, 13/32, (I)

1шт.

179812

GEAR

SCREW, 5/16-18 x 1/2 hex-hd cap

1шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

1шт.

9635082

NUT,5/16" - 18, Gr 5

1шт.

3

363660R1

CLIP

LIP, front harness, 3/4, 3/4, 2-5/8, 13/32, (I)

1шт.

179837

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5

1шт.

120394

WASHER,3/8", SAE

WASHER, 3/64 x 13/16 x .065 znp

1шт.

3

363660R1

CLIP

front harness, alt. rear, 3/4, 3/4, 2-5/8, 13/32. (I)

1шт.

180077

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

5/16 x 3/4 type K

1шт.

120393

BEARING WASHER,5/16", SAE

WASHER, .344 x .688 x .051

1шт.

4

(Not used this application)

1шт.

5

(Not used this application)

1шт.

6

362126R1

CLIP

main harness, 3/4, 3-5/8, 13/32, (I)

1шт.

6

362126R1

CLIP

park lock neutral switch cables, 3/4, 3-5/8, 13/32, (I)

1шт.

6

384557R1

CLIP

main harness, 3/4, 1-5/8, 9/32, (I)

1шт.

179791

BOLT,Hex, 1/4" - 20 x 1/2", Gr 5

1шт.

492-11025

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

1шт.

109084

NUT,1/4"-20, G5

1шт.

6

362123R1

CLIP

front harness, 3/4, 2-1/8, 15/32, (I)

1шт.

179812

GEAR

SCREW, 5/16-18 x 1/2 hex-hd cap

1шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

1шт.

9635082

NUT,5/16" - 18, Gr 5

1шт.

6

384554R1

CLIP

headlight & horn cable, 3/4, 1-35/64, 13/32, (I)

1шт.

179791

BOLT,Hex, 1/4" - 20 x 1/2", Gr 5

1шт.

95-11028

WASHER,1/4"

1/4 x 5/8 x .051

1шт.

6

362120R1

CLAMP,9.53mm ID, 10.32mm Bolt Hole, P Type

CLIP, head light cable, 3/4, 1-9/16, 13/32, (I)

2шт.

6

366460R1

CABLE CLIP

CLIP, ether solenoid cable, 3/4, 1-1/4, 13/32, (I)

2шт.

179812

GEAR

SCREW, 5/16-18 x 1/2 hex-hd cap

1шт.

6

362120R1

CLAMP,9.53mm ID, 10.32mm Bolt Hole, P Type

CLIP, neutral start cables, 3/4, 1-9/16, 13/32, (I)

1шт.

6

146421C1

CLAMP

CLIP, battery cable short, 3/4, 2-1/8, 15/32, (I), replaces 362123R1

2шт.

6

362666R1

CLIP

solenoid switch cables, 3/4, 2-1/8, 15/32, (I)

1шт.

6

366460R1

CABLE CLIP

CLIP, RH brakes press switch cables, 3/4, 1-1/4, 13/32, (I)

1шт.

179791

BOLT,Hex, 1/4" - 20 x 1/2", Gr 5

1шт.

492-11025

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

1шт.

109084

NUT,1/4"-20, G5

1шт.

Выбрано товаров: 42
