Запчасти Case IH 5088 (13-17) - SUPERSTRUCTURE, DELUXE HYDRAULIC SEAT, SEARS (05) - SUPERSTRUCTURE

Схема запчастей Case IH 5088 - (13-17) - SUPERSTRUCTURE, DELUXE HYDRAULIC SEAT, SEARS (05) - SUPERSTRUCTURE
3
13
4
9
5
11
8
12
5
6
10
14
2
1
6
11
7
12

Артикул

Название

Примечание

Количество

1267557C91

SEAT

ASSY, hydraulic, Western cab, brown

1шт.

1267385C91

SEAT ASSY.

SEAT ASSY, hydraulic, burgundy cab

1шт.

1

1255794C1

SLIDE

ASSY W/HANDLE

1шт.

2

139064C1

SLIDE

ASSY W/O HANDLE

1шт.

3

139066C1

ROD

latch connecting

1шт.

4

64926C1

SPRING

slide adjuster

2шт.

5

143436C1

CUSHION

seat, Western, brown

1шт.

5

143430C1

SEAT

CUSHION, seat, burgundy

1шт.

6

143437C2

CUSHION

back, Western, brown

1шт.

6

143431C2

CUSHION

back, burgundy

1шт.

7

245988C1

ARM

KIT, LH armrest, Western, brown, Replaces 1267698C1, Consists of armrest assy, bolt, plate, screw and washer

1шт.

ARMREST ASSY, LH (NSS)

1шт.

BOLT, armrest stop (NSS)

2шт.

PLATE, LH cover (NSS)

1шт.

SCREW, tapping (NSS)

1шт.

WASHER, spring (NSS)

1шт.

7

83816C1

KIT

LH armrest, burgundy, Replaces 1262346C1, Consists of armrest assy, bolt, plate, screw and washer

1шт.

ARMREST ASSY, LH (NSS)

1шт.

BOLT, armrest stop (NSS)

2шт.

PLATE, LH cover (NSS)

1шт.

SCREW, tapping (NSS)

1шт.

WASHER, spring (NSS)

1шт.

8

245989C1

KIT

RH armrest, Western, brown, Replaces 143439C1, Consists of armrest assy, bolt, plate, screw and washer

1шт.

ARMREST ASSY, RH (NSS)

1шт.

BOLT, armrest stop (NSS)

2шт.

PLATE, RH cover (NSS)

1шт.

SCREW, tapping (NSS)

1шт.

WASHER, spring (NSS)

1шт.

8

83817C1

KIT

RH armrest, burgundy, Replaces 143433C1, Consists of armrest assy, bolt, plate, screw and washer

1шт.

ARMREST ASSY, RH (NSS)

1шт.

BOLT, armrest stop (NSS)

2шт.

PLATE, RH cover (NSS)

1шт.

SCREW, tapping (NSS)

1шт.

WASHER, spring (NSS)

1шт.

9

139067C1

SCREW,1/4" - 20 x 0.38"

armrest stop

3шт.

10

637970C1

PLATE

cover LH

1шт.

27959R1

SELF-TAP SCREW,Cross Pan Hd, #10 x 1 1/2"

SCREW, #10-16 x 1-1/2 phc p/hdcr tap

1шт.

10

139072C1

PLATE

cover RH

1шт.

27049R1

SELF-TAP SCREW,Cross Pan Hd, #10 x 5/8"

SCREW, #10-16 x 5/8 phc p/hdcr tap

1шт.

11

245987C1

SAFETY BELT

SAFETY BELT, Western, Brown, Replaces 143440C1, Consists of Bolt and Nut

1шт.

BELT ASSY, seat (NSS)

1шт.

BOLT, hex-hd (NSS)

2шт.

NUT, center lock (NSS)

2шт.

11

245998C1

BELT

KIT, seat belt, burgundy, replaces 143434C1, Consists of belt assy, bolt and nut

1шт.

BELT ASSY, seat (NSS)

1шт.

BOLT, hex-hd (NSS)

2шт.

NUT, center lock (NSS)

2шт.

12

1262062C1

CUSHION

upper backrest, Western, brown

1шт.

12

143435C1

CUSHION

upper backrest, burgundy, Not furnished as part of seat

1шт.

13

1267543C1

KNOB

ASSY, backrest adj.

2шт.

14

1267544C1

LEVER

ASSY, seat tilt

1шт.
