Запчасти Case IH 3788 (10-19) - HYDRAULICS, RESERVOIR AND FILTER (07) - HYDRAULICS

Схема запчастей Case IH 3788 - (10-19) - HYDRAULICS, RESERVOIR AND FILTER (07) - HYDRAULICS
3
14
21
15
18
15
6
4
19
8
2
5
21
17
11
7
12
20
16
16
9
13
10

Артикул

Название

Примечание

Количество

1

HOSE, suction, For service, Order ref. nos. 18, 19, 20 and 21

1шт.

17427R1

BOLT, 7/16 x 1 pln type 1

4шт.

2

22278R1

O-RING,0.103" Thk x 1.674" ID, -131, Cl 5, 75 Duro

1-11/16 x 1-7/8 x 3/32

1шт.

3

382257R2

GASKET

oil filter cover

1шт.

4

138170C1

FRAME

ASSY, filter

1шт.

NLS

NO LONGER SERVICED

8шт.

5

285253R1

O-RING,0.139" Thk x 5.484" ID, -254, Cl 5, 75 Duro

5-1/2 x 5-3/4 x 1/8 filter frame

1шт.

6

9410358

PLUG

9/16-18 hyd str-thd o-ring boss

1шт.

7

364839R1

O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro

6-1, 90 Duro, .468" ID x .078" Thk, 15/32 OD tube

1шт.

8

COVER, filter frame, For service, Order ref. nos. 18, 19, 20 and 21

1шт.

480288C1

STUD

2шт.

120376

NUT,5/16"-18, G5

2шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

2шт.

9

CONNECTOR, 2-1/2-12 hyd 37 deg flared tube short swivel, For service, Order ref. nos. 18, 19, 20 and 21

1шт.

10

307916R1

O-RING,0.118" Thk x 2.337" ID, -932, Cl 6, 90 Duro

2 OD tube class 6

1шт.

11

133685C2

MANIFOLD

suction line

1шт.

12

293726R1

O-RING,0.139" Thk x 2.234" ID, -228, Cl 5, 75 Duro

2-1/4 x 2-1/2 class 5

1шт.

13

133686C1

SUPPORT

suction line manifold

1шт.

14

133728C1

RETAINER

filter cartridge

1шт.

15

142785C91

VALVE

by-pass, Replaces 133735C1

1шт.

16

133736C1

FILTER, ELEMENT

ELEMENT, hyd oil filter

2шт.

16

1263437C1

FILTER, ELEMENT

ELEMENT, 3 in. hyd oil filter, For clean up use only, See service manual

2шт.

17

FRAME ASSY, rear, refer to rear frame, covers and connections listing group 7

1шт.

18

142847C1

HOSE

suction

1шт.

17427R1

BOLT, 7/16 x 1 pln type 1

4шт.

19

301016R1

O-RING,0.118" Thk x 1.720" ID, -924, Cl 6, 90 Duro

1-1/2 O.D. tube

1шт.

20

145462C1

COVER

filter frame

1шт.

480288C1

STUD

2шт.

120376

NUT,5/16"-18, G5

2шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

2шт.

21

290045R1

FLANGE

split

2шт.

Выбрано товаров: 31
