Запчасти Case IH 3788 (10-04) - HYDRAULICS, POWER STEERING PUMP DRIVE HOUSING (07) - HYDRAULICS

Схема запчастей Case IH 3788 - (10-04) - HYDRAULICS, POWER STEERING PUMP DRIVE HOUSING (07) - HYDRAULICS
5
8
5
26
21
9
13
25
24
17
26
6
11
20
12
1
4
12
6
7
27
14
10
22
3
16
2
15
10
23
19
18

Артикул

Название

Примечание

Количество

1

138919C93

HOUSING

ASSY, pump drive, Includes ref 2 & 3

1шт.

179840

BOLT,Hex, 3/8" - 16 x 1 1/8", Gr 5

3/8 x 1-1/8 pln type 5

14шт.

186282

BOLT,Hex, 3/8" - 16 x 3 1/4", Gr 5

3/8 x 3-1/4 pln type 5

1шт.

104938

PLUG

#2 cork

1шт.

2

20024R1

PIN

3/8 x 1 pln hdn dowel

2шт.

3

318300R1

PLUG,Cup, 1"

1.000 cup

1шт.

4

134531C3

GASKET

pump drive housing

1шт.

5

9410364

PLUG

1-5/8, 12 o-ring boss

2шт.

6

307915R1

O-RING,0.118" Thk x 1.475" ID, -920, Cl 6, 90 Duro

1-1/4 tube

2шт.

7

9409948

PLUG,Sq Soc, 3/4"-14 NPTF

3/4-14 auto sq-soc pipe stl

1шт.

8

134491C2

SHAFT

idler gear

1шт.

9

355965R1

O-RING,0.139" Thk x 0.921" ID, -213, Cl 5, 75 Duro

15/16 x 1-3/16 x 1/8 idler gear shaft

1шт.

10

134492C1

THRUST WASHER

thrust, idler gear

2шт.

11

134457C1

GEAR

idler

1шт.

12

134469C91

NEEDLE BEARING

ASSY, idler gear needle

2шт.

13

454417R1

SNAP RING,#100, Ext

Ring, Snap, , idler gear #100, Ext

1шт.

20690R1

PIN,1/4" x 3/4", Coiled

1шт.

14

134458C1

SHAFT

pump drive

1шт.

15

134455C1

GEAR

pump drive 27T

1шт.

16

134476C1

THRUST WASHER

spacer, drive gear

1шт.

17

301020R1

SNAP RING,#118, Ext

Ring, Snap, , pump drive gear #118, Ext

1шт.

18

ST300

BALL BEARING,25 mm ID x 62 mm OD x 17 mm

BEARING ASSY, ball

1шт.

19

454417R1

SNAP RING,#100, Ext

Ring, Snap, , bearing shaft #100, Ext

1шт.

20

641207R1

SNAP RING,2.44", Int, #244

Ring, Snap, , brg housing 2.44", Int, #244

1шт.

21

134462C1

COUPLING, BREAK AWAY

COUPLER, pump drive

1шт.

22

134468C2

SHAFT

ASSY, transmission brake

1шт.

23

369908R1

O-RING,0.103" Thk x 0.799" ID, -117, Cl 5, 75 Duro

13/16 x 1 x 3/32 trans brake shaft

1шт.

24

384311R21

LEVER

ASSY, trans. brake

1шт.

25

126-122

WOODRUFF KEY,#13, 3/16" x 1", HT

KEY, 13/16 x 1 Woodruff 13

1шт.

26

384305R1

RING

retaining

2шт.

27

142025C1

PIN

1/4 x 3/8 pln chamf str

1шт.

Выбрано товаров: 31
