Запчасти Case IH 3688 (10-04[A]) - HYDRAULICS, HYDRAULIC PUMP, CESSNA, 12 GPM (07) - HYDRAULICS

Схема запчастей Case IH 3688 - (10-04[A]) - HYDRAULICS, HYDRAULIC PUMP, CESSNA, 12 GPM (07) - HYDRAULICS
3
4
2
1

Артикул

Название

Примечание

Количество

1

120114C92

PUMP, HYDRAULIC

PUMP ASSY, hydraulic, Includes Ref. 2, 3 and 4

1шт.

1

1949302C1

REMAN-HYD PUMP

3088, 3288, 3688, 3688HC, All INTERNATIONAL DIESEL TRACTOR, PUMP ASSY (1/81-12/86)

1шт.

1

1949303C1

CORE-HYDRAULIC PUMP

Return Number

1шт.

1

120114C92GV

PUMP

PUMP ASSY, hydraulic, Includes Ref. 2, 3 and 4

1шт.

1

1949302C1

REMAN-HYD PUMP

Remanufactured HYDRAULIC PUMP - for N.A. Only

1шт.

1

1949303C1

CORE-HYDRAULIC PUMP

Return No, HYDRAULIC PUMP - for N.A. Only

1шт.

2

531530R1

LARGE PLATE

PLATE, washer

1шт.

*

528174R1

SCREW

5/16-18 spec. hex-hd cap

2шт.

3

383534R91

OIL SEAL

pump drive shaft

1шт.

4

383539R1

KEY

pump drive shaft

1шт.

*

63687C2

SEAL KIT

KIT, hydraulic pump o-ring and gasket service, Consists of

1шт.

*

DIAPHRAGM (NSS)

1шт.

*

GASKET (NSS)

1шт.

*

GASKET (NSS)

1шт.

*

DIAPHRAGM (NSS)

1шт.

*

PLATE (NSS)

1шт.

*

SEAL (NSS)

1шт.

*

INSTRUCTIONS (NSS)

1шт.

Выбрано товаров: 18
