Запчасти Case IH 3488 (02-01) - MISCELLANEOUS, PACKAGES Accessories & Attachments / Miscellaneous

371418R91

PACKAGE

front wheel bearing overhaul, Consists of

1шт.

G15215

ROLLER BEARING

BEARING ASSY front wheel inner cone

1шт.

619387R1

BEARING CUP

BEARING front wheel inner cup

1шт.

618023R91

BEARING ASSY,34.93mm ID x 18.2mm W

BEARING ASSY front wheel outer cone

1шт.

618024R1

BEARING CUP,65.113mm OD x 13.97mm W

Front wheel outer

1шт.

369860R1

GASKET,0.79mm Thk

front wheel hub cap

1шт.

370254R91

OIL SEAL,57.02mm ID x 82.55mm OD x 6.86mm Thk

ASSY front wheel oil

1шт.

48703D

RETAINER

front wheel oil seal

1шт.

1272428C91

SEAL PACKAGE

PACKAGE chassis overhaul O-ring, replaces 386682R96, Consists of

1шт.

35221R1

O-RING cam pivot and selector drive, 9/16 x 3/4 class 5

2шт.

252483R1

O-RING,-218, 70 Duro, 1.234" ID x .139" Thk

clutch housing suction tube, 1-1/4 x 1-1/2 class 5

2шт.

70253R1

O-RING clutch housing suction tube, 1-1/2 x 1-3/4 x 1/8

1шт.

264681R1

O-RING,0.139" Thk x 6.48" ID, -260, Cl 5, 75 Duro

rear axle cap, 6-1/2 x 6-3/4 class 5

2шт.

381884R1

O-RING,0.103" Thk x 0.987" ID, -120, Cl 6, 90 Duro

cover to seat support, small, 1 x 1-3/16 class 6

3шт.

386867R1

O-RING,0.103" Thk x 1.11" ID, -122, Cl 6, 90 Duro

cover to seat support, 1-1/8 x 1-5/16 class 6

1шт.

384377R1

O-RING,0.103" Thk x 2.55" ID, -141, Cl 6, 90 Duro

cover to seat support, large, 2-5/16 x 2-1/2 class 6

1шт.

360610R1

O-RING,1.609" ID x 0.139" Width

hydraulic filter suction tube, 1-5/8 x 1-7/8 class 5

1шт.

293726R1

O-RING,0.139" Thk x 2.234" ID, -228, Cl 5, 75 Duro

hyd filter suction tube, 2-1/4 x 1/8

1шт.

382997R1

O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro

park lock actuating shaft, 1/2 x 5/8 class 6

1шт.

352221R1

O-RING,0.103" Thk x 0.549" ID, -113, Cl 5, 75 Duro

cam pivot shaft, 9/16 x 3/4 class 5

1шт.

355966R1

O-RING,0.424" ID x 0.103" Width

reverse shift pivot arm shaft, 7/16 x 5/8 class 5

1шт.

385744R1

SEALING RING

rear frame pressure port oil

2шт.

388306R1

RING,32.77mm ID x 39.12mm OD x 3.17mm Thk

SEAL rear frame pressure port oil

1шт.

387926R2

RING

O-RING seal draft control port cover

2шт.

128359

O-RING,0.07" Thk x 0.614" ID, -16, Cl 5, 75 Duro

rear frame cover shift shaft, 5/8 x 3/4 class 5

2шт.

529133R1

RING

rear axle carrier cap sealing

2шт.

381885R1

O-RING,0.103" Thk x 1.362" ID, -126, Cl 6, 90 Duro

1-3/8 x 1-9/16 class 6

1шт.

79021C92

PACKAGE

chassis overhaul gasket, Consists of

1шт.

224903C1

GASKET

clutch housing

1шт.

384078R1

GASKET

clutch housing bottom cover

1шт.

380112R1

GASKET

clutch housing cover

1шт.

383330R1

GASKET

draft control adj opening cover

1шт.

385757R1

GASKET

drive att opening cover

1шт.

369860R1

GASKET,0.79mm Thk

front wheel hub

2шт.

23977DD

GASKET,47.5mm ID x 65.89mm OD x 2.39mm Thk

fuel tank filler cap

1шт.

381467R1

GASKET

independent PTO opening cover

1шт.

382257R2

GASKET

oil filter cover

1шт.

382244R4

GASKET

pump opening cover

1шт.

1341531C2

GASKET pump drive housing

1шт.

380225R2

GASKET

rear axle carrier

2шт.

380225R2

GASKET

rear axle carrier

2шт.

380264R2

GASKET

rear frame cover

1шт.

380315R1

GASKET

rear frame, front cover

1шт.

382416R1

GASKET

valve adj oprning cover

1шт.

127562C1

PLUG

lube oil, instructions

1шт.

127562C1

PLUG

INSTRUCTIONS

1шт.

534791R91

GASKET

PACKAGE hydrostatic transmission gasket service, Consists of

1шт.

406498R1

GASKET

bottom front cover

1шт.

406500R1

GASKET

bottom cover rear

1шт.

396796R1

GASKET

cam pivot shaft housing

1шт.

406507R2

GASKET

drive housing to rear frame

1шт.

406495R2

GASKET

drive housing top cover

1шт.

396042R1

GASKET

left side cover

1шт.

406506R1

GASKET

lub block

1шт.

406716R2

GASKET

multiple control valve, HV

1шт.

406717R2

GASKET

multiple control valve, LT

1шт.

406548R1

GASKET

multi-valve body

1шт.

406502R1

GASKET

right side cover

1шт.

534792R91

STRIPPER PACKAGE

PACKAGE hydrostatic transmisson O-ring service, Consists of

1шт.

369384R1

O-RING,0.072" Thk x 0.414" ID, -905, Cl 6, 90 Duro

5-1, 90 Duro, .414" ID x .072" Thk, Bulkhead union, 5/16 OD tube class 6

2шт.

383024R1

O-RING,0.07" Thk x 0.676" ID, -17, Cl 6, 90 Duro

charge tube fitting, 11/16 x 13/16 class 6

1шт.

298385R1

O-RING,0.07" Thk x 0.676" ID, -17, Cl 5, 75 Duro

connector tube, 11/16 x 13/16 class 5

1шт.

254954R1

O-RING,0.139" Thk x 1.046" ID, -215, Cl 5, 75 Duro

filter base, 1-1/16 x 1-5/16 class 5

2шт.

369751R1

O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro

4-1, 90 Duro, .351" ID x .072" Thk, 1/4 OD tube, class 6, Flared tube elbow & servo pressure port plug

3шт.

23072R1

O-RING,11.975" ID x 12.525" OD x 0.275"

front bearing support cover 12 x 12-1/2 class 5

1шт.

364839R1

O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro

6-1, 90 Duro, .468" ID x .078" Thk, 3/8 OD tube, class 6, lub block power steering pressure tube elbow & union

3шт.

364885R1

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

lub block union motor lub tube & strainer plug, 5/8 OD tube class 6

3шт.

380910R1

O-RING,0.103" Thk x 2.987" ID, -151, Cl 5, 75 Duro

motor & pump trunnion, 3 x 3-3/16 class 5

4шт.

570828R1

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

power steering return tube union, 1/2 OD tube class 6

6шт.

379457R1

O-RING,0.103" Thk x 2.175" ID, -139, Cl 5, 75 Duro

PTO front bearing cover, 2-3/16 x 2-3/8 class 5

1шт.

254691R1

O-RING,-211, 70 Duro, .796" ID x .139" Thk

pump pressure port large, 13/16 x 1-1/16 class 5

1шт.

352221R1

O-RING,0.103" Thk x 0.549" ID, -113, Cl 5, 75 Duro

pump pressure port small, 9/16 x 3/4 class 5

1шт.

252483R1

O-RING,-218, 70 Duro, 1.234" ID x .139" Thk

pump suction port, 1-1/4 x 1-1/2 class 5

1шт.

295204R1

O-RING,0.103" Thk x 2.8" ID, -149, Cl 5, 75 Duro

retainer, 2-13/16 x 3 class 5

1шт.

379365R1

O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro

servo charge tube retainer, 3/8 x 1/2 class 6

1шт.

307915R1

O-RING,0.118" Thk x 1.475" ID, -920, Cl 6, 90 Duro

shuttle valve access plug, 1-1/4 OD tube class 6

1шт.

406659R1

RING

anchor shaft support bushing

1шт.

406657R1

RING

control cylinder anchor shaft sealing

3шт.

66067C2

SEAL

SEAL charge tube

2шт.
