Запчасти Case IH 2590 (4-086) - TRANSMISSION HARNESS, P.I.N. 8841101 AND AFTER (04) - ELECTRICAL SYSTEMS

1

A162761

HARNESS

- transmission (Replaces A160585)

1шт.

2

A66737

SWITCH, PRESSURE

SWITCH - transmission filter pressure

1шт.

3

A162422

SWITCH

- transmission oil pressure

1шт.

4

A160237

SWITCH

- neutral start

2шт.

5

A160890

STRAP

- nylon, harness (Replaces L11541)

2шт.

6

A147345

HARNESS

- front flood lamps

1шт.

7

A147346

HARNESS

WIRE - front flood lamps

2шт.

8

A145495

LAMP

- front flood (See Figure 4-142)

2шт.

9

A147344

ELECTRICAL WIRE

WIRE - front flood ground

2шт.

10

113-205

BOLT,Hex, 3/8" - 16 x 5/8", Gr 5

1шт.

11

A38066

CLIP

- wire to PTO housing

1шт.

12

A161432

FITTING

SNUBBER - pressure switch (Replaces A155051)

1шт.

13

A154283

SWITCH

- transmission temperature

1шт.
