(9-384) - CAB, HEADLINER AND LOUVERS, CAB SERIAL NUMBER 12013067 THROUGH 12050250

Запчасти Case IH 2590 (9-384) - CAB, HEADLINER AND LOUVERS, CAB SERIAL NUMBER 12013067 THROUGH 12050250 (09) - CHASSIS/ATTACHMENTS

Схема запчастей Case IH 2590 - (9-384) - CAB, HEADLINER AND LOUVERS, CAB SERIAL NUMBER 12013067 THROUGH 12050250 (09) - CHASSIS/ATTACHMENTS
26
4
3
23
25
8
27
19
15
11
24
9
1
5
7
22
16
10
18
12
26
2
17
4
6
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

F64314

LINING

HEADLINER - cab (Without radio)

1шт.

2

F64244

LINING

HEADLINER - cab (With radio)

1шт.

3

F63799

MOLDING

TRIM - rear, headliner

1шт.

4

F63800

MOLDING

TRIM - side, headliner

2шт.

5

187-1084

SELF-TAP SCREW,Cross Oval Hd, #10 x 3/4"

SCREW - #10-16 x 3/4" Phillips, self tapping

22шт.

6

F64315

WASHER

- finishing

22шт.

7

F98171

LAMP

ASSEMBLY - courtesy, Includes: Ref. 8

1шт.

8

D71346

TAIL LAMP,12V

BULB - lamp, No. 168

1шт.

9

187-1062

SELF-TAP SCREW,Cross Oval Hd, #10 x 1/2"

SCREW - #10-24 x 1/2" Phillips, self tapping

2шт.

10

F64132

GUARD

LOUVER - air deflection, ball type

4шт.

11

F64131

RING

- retainer, louver

4шт.

12

F89948

GUARD

LOUVER - air deflection, rectangle

2шт.

15

F98149

GUARD

LOUVER - defroster

1шт.

16

321-3842

DECAL

- defroster

1шт.

17

F89772

LAMP

ASSEMBLY - dome, Includes: Ref. 18

1шт.

18

B50217

BULB

- lamp

1шт.

19

151-526

RIVET,Pop, 1/8" x .337"

4шт.

22

F64130

SWITCH

- dome lamp

1шт.

23

F64355

BRACKET

- coat hook

1шт.

24

F64352

HOOK

- coat

1шт.

25

182-534

SCREW,Sl Pan Hd, 1/4" - 20 x 1"

- 1/4-20 x 1" flat slotted head

1шт.

26

86625061

NUT,1/4"-20, GB

NUT - 1/4" NC hex

1шт.

27

F64386

COVER

- radio rear

1шт.

28

187-1095

SELF-TAP SCREW,Hex Wash Hd, #8 x 1/2"

SCREW - #8-18 x 1/2" round head self tapping

4шт.
