Запчасти Case IH 2290 (7-350) - DIFFERENTIAL LOCK MECHANISM, TRANSMISSION SERIAL NUMBER 10211449 AND AFTER (07) - BRAKES

1

A141692

PEDAL

- foot

1шт.

2

132-337

COTTER PIN,1/8" x 1 3/4"

1/8" x 1 3/4"

1шт.

3

113-102

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

Hex, 5/16"-18 x 3/4", G5, Full Thd, Valve

4шт.

4

218-453

HYD CONNECTOR,9/16" - 18 Male JIC x 1/8" - 27 Male NPTF

CONNECTOR, HYD., , Regulator valve, 3/8 tube 9/16"-18, 37º x 1/8"-27, NPTF

1шт.

5

A160081

HOSE

- regulator valve to differential lock valve

1шт.

6

218-5352

HYD CONNECTOR,9/16"-18, 37 Degree x 7/16"-20, O-Ring

CONNECTOR ASSEMBLY - 3/8 tube x 7/16-20 inch, Includes: Ref. 7

1шт.

7

218-5003

O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro

- 11/32 x 1/2 x 5/64 inch (9 x 13 x 2 MM)

1шт.

8

A160129

TUBE

- front, brake valve to lock valve

1шт.

9

A163860

TUBE

- rear, brake valve to lock valve (Replaces A160130)

1шт.

10

218-5103

90 ELBOW,90 Degree Elbow, 7/16" - 20 Male JIC x 7/16" - 20 Male ORB

ASSEMBLY - lock valve, 1/4 tube x 7/16-20 inch, Includes: Ref. 11

1шт.

11

218-5003

O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro

- 11/32 x 1/2 x 5/64 inch (9 x 13 x 2 MM)

1шт.

12

218-5053

HYD CONNECTOR,7/16" - 20 JIC x 7/16" - 20 ORB

CONNECTOR ASSEMBLY - brake valve, 1/4 tube x 7/16-20 inch, Incl. Ref. 13

1шт.

13

218-5003

O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro

- 11/32 x 1/2 x 5/64 inch (9 x 13 x 2 MM)

1шт.

14

218-5278

ELBOW,9/16" - 18 JIC x 7/16" - 20 ORB

ASSEMBLY - brake valve, 3/8 tube x 9/6-20 inch, Incl. Ref. 15

1шт.

15

218-5003

O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro

- 11/32 x 1/2 x 5/64 inch (9 x 13 x 2 MM)

1шт.

16

A160082

HOSE

- lock valve to transmission case

1шт.

17

218-5058

HYD CONNECTOR,9/16" - 18 Male JIC x 3/4" - 18 Male ORB

CONNECTOR ASSEMBLY - transmission case, 3/8 tube x 1/2-20 inch, Includes: Ref. 18

1шт.

19

515-2363

CLAMP,M6.3, Insul, 3/8" Bolt

- hose

1шт.

20

A63670

TUBE

- nylon, brake valve return, 3/8 OD x 30 inch (Order A67323)

1шт.

21

222-2646

ELBOW,90 Degree, 17/32"-24 x 1/8" NPT, Comp

ASSEMBLY - 3/8 inch tube (See inset A), Includes: Ref. 22, 23

2шт.

22

222-2611

SLEEVE

- 3/8 inch tube (See inset A)

1шт.

23

222-2601

NUT

NUT - 3/8 inch tube (See inset A)

1шт.

21

222-5112

FITTING,9/16"-24 x 1/4" NPTF

ELBOW ASSEMBLY - 3/8 tube (See inset B) (Order 222-2646), Includes: Ref. 22, 23

1шт.

22

222-5186

SLEEVE,3/8" Tube

- 3/8 inch tube (See inset B)

1шт.

23

222-5181

NUT,9/16"-24

NUT - 3/8 inch tube (See inset B)

1шт.

24

A63997

TUBE

- nylon, brake valve return, 3/8 OD x 25 inch (Order A67323)

1шт.

25

222-2651

HYD CONNECTOR,17/32"-24

UNION - tube, 3/8 inch tube, Includes: Ref. 26, 27

1шт.

26

222-2611

SLEEVE

- 3/8 inch tube

2шт.

27

222-2601

NUT

NUT - 3/8 inch tube

2шт.

28

222-5101

CONNECTOR, ELEC,17/32"-24 x 1/4" NPT

CONNECTOR ASSEMBLY - dipstick tee, 3/8 tube x 1/4 inch PT, Includes: Ref. 29, 30

1шт.

29

222-5186

SLEEVE,3/8" Tube

- 3/8 inch tube

1шт.

30

222-5181

NUT,9/16"-24

NUT - 3/8 inch tube

1шт.

31

A161146

FITTING

TEE - dipstick

1шт.

35

A145792

TUBE

- nylon, lock valve return, 3/8 OD x 12 inch (Order A67323)

1шт.

39

222-2631

FITTING,17/32"-24 x 1/8" NPT Fem, Comp

CONNECTOR ASSEMBLY - straight, 3/8 inch tube (See inset A), Includes: Ref. 40, 41

1шт.

40

222-2611

SLEEVE

- 3/8 inch tube (See inset A)

1шт.

41

222-2601

NUT

NUT - 3/8 inch tube (See inset A)

1шт.

39

222-5100

CONNECTOR, ELEC,17/32"-24 x 1/8" NPT

CONNECTOR ASSEMBLY - 3/8 inch tube (See inset B) (Order 222-2631), Includes: Ref. 40, 41

1шт.

40

222-5186

SLEEVE,3/8" Tube

- 3/8 inch tube (See inset B)

1шт.

41

222-5181

NUT,9/16"-24

NUT - 3/8 inch tube (See inset B)

1шт.

42

L18337

CABLE TIE,9.95"-12.1" lg

STRAP - tie, 15 inch, nylon

1шт.

43

REF

INSTRUCTION

VALVE ASSEMBLY - differential lock (See Figure 7-352)

1шт.

A67323

TUBE

- service, nylon 3/8 OD x 132 inch

1шт.

18

218-5006

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

- 41/64 x 13/16 x 3/32 inch (16 x 21 x 2 MM)

1шт.
