Артикул
Название
Примечание
Количество
1
400711R1
SEAT CUSHION
CUSHION ASSY, seat
1шт.
2
381292R93
BASE
ASSY, adjustable seat
1шт.
2
530336R93
BASE ASSY, adjustable seat w/stops, tractors with cab, for components see list of parts under details of adjustable seat base, Fig. 13-12
1шт.
3
387172R1
SUPPORT
back cushion LH
1шт.
120377
NUT,3/8" - 16, Gr 5
2шт.
180121
BOLT,Hex, 3/8" - 16 x 7/8", Gr 5
SCREW, 3/8-16 x 7/8 C-Z hex-hd cap
2шт.
138542
LOCK WASHER,Int Tooth, 3/8"
WASHER, LOCK, Int Tooth, 3/8"
4шт.
4
387174R91
CUSHION
ASSY, back
1шт.
5
387175R1
LARGE PLATE
PLATE, cover
1шт.
260-1446
SELF-TAP SCREW,Cross Pan Hd, #8 x 3/8"
8-15 x 3/8 cr-rec pan-hd type A tapping
3шт.
6
387178R1
SUPPORT
upper back cushion
1шт.
7
387177R91
CUSHION
ASSY, upper back
1шт.
180075
BOLT,Hex, 5/16" - 18 x 5/8", Gr 5
SCREW, 5/16-18 x 5/8 C-Z hex-hd cap
2шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
2шт.
138542
LOCK WASHER,Int Tooth, 3/8"
WASHER, LOCK, Int Tooth, 3/8"
2шт.
8
380720R1
BOLT,5/16"- 18 x 0.75"
front bulkhead
4шт.
9635082
NUT,5/16" - 18, Gr 5
5/16-18 hex.
4шт.
9
380719R1
SUPPORT
BULKHEAD, front
1шт.
10
372739R1
PIN, adjusting
1шт.
11
379319R93
SUPPORT
SUSPENSION ASSY, vertical acting
1шт.
12
380724R2
FRAME
hanger
1шт.
13
380722R1
SHAFT
short link upper
2шт.
443039
PIN
1/4 x 1-1/4 type 3 groove
2шт.
14
380723R1
SHAFT
short link lower
2шт.
443148
GROOVED PIN,3/16" x 1", Type E
Pin, Grooved, 3/16" x 1", Type E
2шт.
15
380721R1
DRAG LINK
LINK, short
2шт.
16
380713R1
LEVER
LH spring
1шт.
17
193643R1
BUSHING,19.18mm ID x 25.4mm OD x 14.29mm L
BEARING, flanged
2шт.
18
380712R1
INSULATOR BLOCK
SPRING, rubber
2шт.
19
380718R1
WASHER
49/64 x 1-1/4 x 14 ga
2шт.
20
380717R1
LINK
stabilizer
1шт.
21
370290R1
SNAP RING,#50, .392" Dia, E-Type
Ring, Retaining, #50, .392" Dia, E-Type
4шт.
22
380714R1
LEVER
RH spring
1шт.
23
SL716
WASHER
13/32 x 1-1/8 x 14 ga
2шт.
24
381239R1
RUBBER WASHER
rubber
2шт.
25
380715R1
YOKE
BRACKET, LH shock
1шт.
26
381238R1
BUMPER
rubber
2шт.
27
372751R91
SHOCK ABSORBER
ABSORBER, shock
1шт.
274635
PIN
NUT, 3/8-24 C-Z hex. lock
2шт.
28
380716R1
YOKE
BRACKET, RH shock
1шт.
29
380711R2
HOUSING
spring
1шт.
30
380726R1
SPRING
INDICATOR, weight
1шт.
31
380725R91
STUD
ASSEMBLY, adjuster
1шт.
142488
GROOVED PIN,1/8" x 1", Type A
Pin, Grooved, 1/8" x 1", Type A
2шт.
32
387173R1
SUPPORT
back cushion RH
1шт.
120377
NUT,3/8" - 16, Gr 5
2шт.
180121
BOLT,Hex, 3/8" - 16 x 7/8", Gr 5
SCREW, 3/8-16 x 7/8 C-Z hex-hd cap
2шт.
138542
LOCK WASHER,Int Tooth, 3/8"
WASHER, LOCK, Int Tooth, 3/8"
4шт.
33
379321R1
CLAMP,27.74mm ID, 8.71mm Bolt Hole, J Type
seat
2шт.
120376
NUT,5/16"-18, G5
2шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
2шт.
2751019R1
DECAL
PRODUCT GRAPHIC, seat adjustment
1шт.
Выбрано товаров: 56
