Артикул
Название
Примечание
Количество
1
359984R92
ROD
ASSY, tie, welded end
2шт.
2
358901R1
SLOTTED NUT
tie rod
4шт.
3
387280R2
COVER
dust
4шт.
4
109461
LUBE NIPPLE,1/8"-27 x .66 lg
NIPPLE, LUBE, , PTF 1/8"-27 x .66 lg
4шт.
5
359986R1
CLAMP
tie rod, adj end
2шт.
25-118
NUT,1/2"-20, G5
1/2-20 hex.
2шт.
181436
BODY,Hex, 1/2" - 20 x 2 1/4", Gr 5
SCREW, 1/2-20 x 2-1/4 hex-hd cap
2шт.
6
383917R1
TUBE
tie rod
2шт.
7
374062R1
JAM NUT
NUT, jam
2шт.
8
384006R92
END
ASSY, tie rod, RH thread
2шт.
9
383915R92
ROD
ASSY, tie
2шт.
10
382384R1
SUPPORT
BRACKET, auxiliary stay rod front lower RH
1шт.
11
358970R1
ARM
steering gear
2шт.
NLS
NO LONGER SERVICED
SCREW, 3/4-10 x 1-1/2 hex-hd cap
4шт.
12
382375R1
SOCKET
stay rod ball
1шт.
13-1052
BOLT,Hex, 5/8" - 11 x 3-1/4", Gr 5
SCREW, 5/8-11 x 3-1/4 hex-hd cap, Course Threads
2шт.
271573
BRACKET
SCREW, 5/8-11 x 4-3/4 hex-hd cap
2шт.
13
379954R1
SHIM
stay rod ball socket cap
1шт.
14
379953R1
CAP
stay rod ball socket
1шт.
15
380008R1
PLATE ASSY.
PLATE, stay rod ball socket cap lock
1шт.
16
382870R11
ROD ASSY, stay
1шт.
427546
JAM NUT,Jam, 1 3/8"-12, G5
1-3/8-12 hex. jam
2шт.
17
10546D
BALL
stay rod
1шт.
18
383914R1
ARM
steering knuckle
2шт.
225861
NUT,5/8"-18, G8
2шт.
223815
BOLT,Hex, 5/8" - 18 x 3", Gr 8
SCREW, 5/8-18 x 3 C-Z hex-hd cap type 4
2шт.
19
369131R91
THRUST BEARING
steering knuckle pivot thrust
2шт.
20
15943DA
SEALING WASHER,60.33mm ID x 72.23mm OD x 4.76mm Thk
Steering knuckle pivot felt
2шт.
21
40093D
WOODRUFF KEY,#127, 1/4" x 2 1/8", HT
KEY, 1/4 x 2-1/8 woodruff 127, steering knuckle arm
2шт.
22
384258R92
STEERING KNUCKLE
KNUCKLE W/OIL SEAL, 370254R91 and shield, 48701D, steering RH
1шт.
108643
COTTER PIN,5/32" x 1 3/8"
Pin, Split (Cotter), 5/32" x 1 3/8"
1шт.
23
358958R2
BUSHING,42.57mm ID x 46.08mm OD x 51.05mm L
steering knuckle pivot pin
4шт.
24
80722
LUBE NIPPLE,3/16" x .55" lg, Drive
FITTING, 3/16 drive type str lub, steering knuckle pivot pin
2шт.
25
370719R31
EXTENSION
W/TWO BUSHINGS, 358958R2, front axle
2шт.
26
48841D
BUSHING,31.03mm ID x 34.62mm OD x 31.75mm L
front axle pivot pin
2шт.
27
358976R31
CENTER AXLE
AXLE ASSY, front
1шт.
28
358978R2
AXLE PIN,31.29mm OD x 217.49mm L
PIN, front axle pivot
1шт.
29
17049R91
LUBE NIPPLE,67.5 Degree, 1/8"-27 NPT x 1.03" lg, Leakproof
FITTING, 1/8-27 PTF 67-1/2 deg lub, front axle pivot pin
1шт.
30
21105R1
HEADED PIN,9.53mm OD x 123.83mm L
PIN, 3/8 x 4-7/8 hd, front axle pivot pin locking
1шт.
103384
COTTER PIN,1/8" x 3/4"
Pin, Split (Cotter), 1/8" x 3/4"
1шт.
31
383909R4
BOLSTER
lower
1шт.
271613
SCREW,Hex, 3/4" - 10 x 2 1/2", Gr 5
3/4-10 x 2-1/2 hex-hd cap
4шт.
32
350557R1
PIN
front axle clamp
2шт.
432-1624
COTTER PIN,1/4" x 1 1/2"
Pin, Split (Cotter), 1/4" x 1 1/2"
2шт.
33
20673R1
BOLT,Hex, 3/4" - 16 x 4 1/4", Gr 8
front axle clamp
4шт.
218197
NUT,3/4"-16, G5
3/4-16 hex.
4шт.
34
350556R1
CLAMP
front axle
4шт.
35
384257R92
STEERING KNUCKLE
KNUCKLE W/OIL SEAL, 370254R91 and shield 48701D, steering LH
1шт.
108643
COTTER PIN,5/32" x 1 3/8"
Pin, Split (Cotter), 5/32" x 1 3/8"
1шт.
36
382871R91
ROD ASSY, auxiliary stay
2шт.
37
382378R1
END
auxiliary stay rod adjustable
2шт.
218197
NUT,3/4"-16, G5
3/4-16 hex.
2шт.
14-1240
BOLT,Hex, 3/4" - 16 x 2-1/2", Gr 5
SCREW, 3/4-16 x 2-1/2 hex-hd cap
2шт.
103326
LOCK WASHER,3/4"
WASHER, LOCK, 3/4"
2шт.
38
359003R1
CLAMP
auxiliary stay rod adj end
2шт.
425-1110
NUT,5/8"-18, G5
2шт.
114-614
BOLT,Hex, 5/8" - 18 x 3", Gr 5
SCREW, 5/8-18 x 3 hex-hd cap
2шт.
114609
LOCK WASHER,Ext Tooth, 5/8"
WASHER, LOCK, Ext Tooth, 5/8"
2шт.
39
382872R1
TUBE,1.25" ID, 1.635" OD, 40.9" Length
auxiliary stay rod
2шт.
40
359004R1
CLAMP
auxiliary stay rod adj end
2шт.
425-1110
NUT,5/8"-18, G5
2шт.
114-614
BOLT,Hex, 5/8" - 18 x 3", Gr 5
SCREW, 5/8-18 x 3 hex-hd cap
2шт.
114609
LOCK WASHER,Ext Tooth, 5/8"
WASHER, LOCK, Ext Tooth, 5/8"
2шт.
193-12
LOCK WASHER,Ext Tooth, 0.52" ID x 0.89" OD, STL, PLN
WASHER, LOCK, Ext Tooth, 1/2"
2шт.
41
382376R1
BOLT
END, auxiliary stay rod threaded
2шт.
218197
NUT,3/4"-16, G5
3/4-16 hex.
2шт.
14-1240
BOLT,Hex, 3/4" - 16 x 2-1/2", Gr 5
SCREW, 3/4-16 x 2-1/2 hex-hd cap
2шт.
42
359006R1
BOLT
BOLT, auxiliary stay rod bracket mounting
8шт.
25-118
NUT,1/2"-20, G5
1/2-20 hex.
8шт.
103323
LOCK WASHER,1/2"
WASHER, LOCK, 1/2"
8шт.
43
382381R1
SUPPORT
BRACKET, auxiliary stay rod front upper LH
1шт.
44
382383R1
SUPPORT
BRACKET, auxiliary stay rod front lower LH
1шт.
45
382382R1
BRACKET
auxiliary stay rod front upper RH
1шт.
Выбрано товаров: 73
