Запчасти Case IH 2090 (7-342) - DIFFERENTIAL LOCK MECHANISM, PRIOR TO TRANSMISSION SERIAL NUMBER 10211449 (07) - BRAKES

1

A141692

PEDAL

- foot

1шт.

2

132-337

COTTER PIN,1/8" x 1 3/4"

1/8" x 1 3/4"

1шт.

3

113-102

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

Hex, 5/16"-18 x 3/4", G5, Full Thd, Valve

4шт.

4

218-453

HYD CONNECTOR,9/16" - 18 Male JIC x 1/8" - 27 Male NPTF

CONNECTOR, HYD., , Regulator valve, 3/8 tube 9/16"-18, 37º x 1/8"-27, NPTF

1шт.

5

A160081

HOSE

- regulator valve to differential lock valve

1шт.

6

218-5352

HYD CONNECTOR,9/16"-18, 37 Degree x 7/16"-20, O-Ring

CONNECTOR ASSEMBLY - 3/8 tube x 7/16-20 inch, Includes: Ref. 7

1шт.

7

218-5003

O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro

- 11/32 x 1/2 x 5/64 inch (9 x 13 x 2 mm)

1шт.

8

A160129

TUBE

- front, brake valve to lock valve

1шт.

9

A163860

TUBE

- rear, brake valve to lock valve (Replaces A160130)

1шт.

10

218-5103

90 ELBOW,90 Degree Elbow, 7/16" - 20 Male JIC x 7/16" - 20 Male ORB

ASSEMBLY - lock valve, 1/4 tube x 7/16-20 inch, Includes: Ref. 11

1шт.

11

218-5003

O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro

- 11/32 x 1/2 x 5/64 inch (9 x 13 x 2 mm)

1шт.

12

218-5053

HYD CONNECTOR,7/16" - 20 JIC x 7/16" - 20 ORB

CONNECTOR ASSEMBLY - brake valve, 1/4 inch tube, Incl. Ref. 13

1шт.

13

218-5003

O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro

- 11/32 x 1/2 x 5/64 inch (9 x 13 x 2 mm)

1шт.

14

218-5278

ELBOW,9/16" - 18 JIC x 7/16" - 20 ORB

ASSEMBLY - lock valve, 90 degrees 3/8 tube x 7/16-20 inch, Incl. Ref. 15

1шт.

15

218-5003

O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro

- 11/32 x 1/2 x 5/64 inch (9 x 13 x 2 mm)

1шт.

16

A160082

HOSE

- lock valve to transmission case

1шт.

17

218-5058

HYD CONNECTOR,9/16" - 18 Male JIC x 3/4" - 18 Male ORB

CONNECTOR ASSEMBLY - transmission case, 1/4 tube x 1/2-20 inch, Includes: Ref. 18

1шт.

19

515-2363

CLAMP,M6.3, Insul, 3/8" Bolt

- hose tube

1шт.

20

A145161

TUBE

- nylon, lock valve to brake valve, 3/8 OD x 55 inch (Order A67323)

1шт.

21

222-5101

CONNECTOR, ELEC,17/32"-24 x 1/4" NPT

CONNECTOR ASSEMBLY - 3/8 tube x 1/4 inch PT (order 222-2626), Includes: Ref. 22 & 23

1шт.

22

222-5186

SLEEVE,3/8" Tube

- 3/8 inch tube (10 mm)

1шт.

23

222-5181

NUT,9/16"-24

NUT - 3/8 inch tube (10 mm)

1шт.

25

A145792

TUBE

- nylon, lock valve to sump, 3/8 OD x 12 inch (Order A67323)

1шт.

26

222-5190

TEE,7/16"-24 x 3/8" NPT Run

FITTING ASSEMBLY - lock valve, 3/8 tube x 3/8 tube x 3/16-24 inch, Includes: Ref. 27 & 28

1шт.

27

222-5186

SLEEVE,3/8" Tube

- 3/8 inch tube (10 mm)

2шт.

28

222-5181

NUT,9/16"-24

NUT - 3/8 inch tube (10 MM)

2шт.

29

222-2631

FITTING,17/32"-24 x 1/8" NPT Fem, Comp

CONNECTOR - straight, 3/8 inch tube (See inset A), Includes: Ref. 30 & 31

1шт.

30

222-2611

SLEEVE

- 3/8 inch tube (See inset A)

1шт.

31

222-2601

NUT

NUT - 3/8 inch tube (See inset A)

1шт.

29

222-5100

CONNECTOR, ELEC,17/32"-24 x 1/8" NPT

CONNECTOR ASSEMBLY - straight, 3/8 inch tube (See inset B) (Order 222-2631), Includes: Ref. 30 & 31

1шт.

30

222-5186

SLEEVE,3/8" Tube

- 3/8 inch tube (10 mm)

1шт.

31

222-5181

NUT,9/16"-24

NUT - 3/8 inch tube (10 mm)

1шт.

32

L18337

CABLE TIE,9.95"-12.1" lg

STRAP - tie, 15 inch, nylon

1шт.

35

REF

INSTRUCTION

VALVE ASSEMBLY - differential lock, See Figure 7-346

1шт.

A67323

TUBE

- service, nylon 3/8 OD x 132 inch (Not shown)

1шт.

18

218-5006

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

- 41/64 x 13/16 x 3/32 inch (16 x 21 x 2 mm)

1шт.
