Запчасти Case IH 2090 (7-328) - BRAKE VALVE CIRCUIT (07) - BRAKES

1

REF

INSTRUCTION

VALVE ASSEMBLY - power brake, See Figure 7-330

1шт.

2

218-5059

HYD CONNECTOR,3/4"-16, 37 Degree x 3/4"-16, O-Ring

CONNECTOR ASSEMBLY - clutch valve, 1/2 tube x 3/4-16 inch, Incl. Ref 3

1шт.

4

A149931

TUBE

- inlet, valve

1шт.

5

A149909

MANIFOLD

- inlet and delay tube

1шт.

6

A160085

TUBE

- wave delay (Order A161248)

1шт.

7

A161248

HOSE

- wave delay (Replaces A160085)

1шт.

8

L18337

CABLE TIE,9.95"-12.1" lg

STRAP - tie, 15 inch, nylon

2шт.

9

A149940

HOSE

- hydraulic, Serial Range: pump-valve

1шт.

10

A147196

MANIFOLD

- valve, Serial Range: outlet-sump

1шт.

11

218-5106

90 ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB

ASSEMBLY - 90 degrees, 1/2 tube x 3/4-16 inch, Includes: Ref. 12

1шт.

3

218-5006

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

- 1/2 x 21/32 x 3/32 inch (13 x 17 x 2 mm)

1шт.

12

218-5006

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

- 1/2 x 21/32 x 3/32 inch (13 x 17 x 2 mm)

1шт.
