Запчасти Case IH 1896 (2-20) - CYLINDER HEAD COVER, 6T-590 ENGINE (02) - ENGINE

1

REF

INSTRUCTION

HEAD - cylinder (See Figure 2-22)

1шт.

2

J902604

COVER

- rocker

6шт.

3

J902666

GASKET

SEAL - rocker cover

6шт.

4

J910824

O-RING,0.07" Thk x 0.364" ID, -12, Cl 5, 75 Duro

- cover bolt (Replaces J901837)

6шт.

5

J907049

BOLT,Hex

- hex flange, 8 mm x 21 mm

6шт.

8

J917358

GASKET

- head, standard (1-Notch) (Replaces J907057)

1шт.

8

J917359

GASKET

- head, 0.23 mm thicker (2-Notches) (Replaces J907058)

1шт.

8

J917360

GASKET

- head, 0.51 mm thicker (3-Notches) (Replaces J907059)

1шт.

9

J908118

BRACKET

- lifting, rear

1шт.

10

813-12025

BOLT,Hex, M12 x 1.75 x 25mm, Cl 8.8, Full Thd

- hex, 12 mm x 25 mm, class 8.8

2шт.

12

J903757

BRACKET

- lifting, front, thermostat and housing

1шт.

13

J903301

GASKET

- housing, and thermostat

1шт.

14

J912587

THERMOSTAT

- water, 95 degree C (Replaces J910706), and housing

1шт.

15

J914409

HOUSING

- thermostat (Replaces J903756)

1шт.

18

J903096

FLANGE BOLT,Hex, M8 x 70mm, Cl 8.8

BOLT - hex flange head, 8 mm x 70 mm, thermostat and housing

2шт.

19

J900632

FLANGE BOLT,Hvy Hex, M8 x 35mm, Cl 8.8

BOLT - hex flange head, 8 mm x 35 mm, thermostat and housing

1шт.

20

J910713

SUPPORT

- alternator mounting (Replaces J908774), thermostat and housing

1шт.

21

813-8025

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd

- flanged head, 8 mm x 25 mm, class 8.8, thermostat and housing

3шт.
