Артикул
Название
Примечание
Количество
A177452
SEAT
ASSEMBLY - operator, complete with suspension unit, Includes: Ref. 1 - 55
1шт.
1
A47761
PLATE
BASE - suspension, upper
1шт.
3
A47764
LEVER
- height adjusting
1шт.
4
A47767
CAP
- lever
1шт.
5
A47381
LATCH
- height adjusting
1шт.
6
138-2024
PIN,5/32" x 1", Coiled
1шт.
7
A47382
SPRING
- latch return
1шт.
8
N6855
KNOB
- weight adjusting
1шт.
9
A45513
GEAR
- weight adjusting
1шт.
10
138-73
LOCK PIN,5/32" x 3/4", Slotted
PIN, 5/32" x 3/4", Slotted
1шт.
11
D82834
WASHER
- thrust
1шт.
12
A45531
BRACKET
- shaft
1шт.
13
411-48
CARRIAGE BOLT,Sq Nk, 1/4" - 20 x 1/2", Gr 2
BOLT - round head, square neck, 1/4 NC x 1/2 inch, grade 2
2шт.
14
131-1351
FLANGE NUT,Flg, 1/4"-20
NUT, LOCK, Flg, 1/4"-20
2шт.
17
138-77
LOCK PIN,5/32" x 1", Slotted
PIN, 5/32" x 1", Slotted
1шт.
18
A45505
GEAR
- weight adjusting
1шт.
19
A45504
SPRING WASHER
- spring
1шт.
20
A45497
SPRING
- suspension, weight
1шт.
21
A45530
PAD
- spring
1шт.
22
N6872
ARM
ASSEMBLY - weight
1шт.
23
A49160
INDICATOR
- ride height
1шт.
24
N6871
SHAFT
- bearing
2шт.
25
A47760
BUSHING
- shaft
4шт.
26
131-1100
LOCK NUT,1/2"-13, GA
NUT, LOCK, 1/2"-13, GA
2шт.
29
A45512
BLOCK
- slider, 1-3/16 inch
1шт.
30
A45516
BLOCK
- slider, 2-3/16 inch
1шт.
31
A45515
BLOCK
- slider, 1-9/16 inch
1шт.
32
A45517
BLOCK
- slider, 2-9/16 inch
1шт.
33
A47359
BOOT
COVER - suspension unit
1шт.
34
151-705
CLIP,Rd 1/2" Hd, 1/4" Hole
- canoe, 1/4 inch
21шт.
37
N6856
DECAL
- adjusting, ride
1шт.
38
A45054
BUMPER,Neoprene
- seat
2шт.
39
138-134
LOCK PIN,1/4" x 1", Slotted
PIN, 1/4" x 1", Slotted
1шт.
40
D82835
SHOCK ABSORBER
ABSORBER - shock, seat
1шт.
41
A45501
BUSHING,0.504" ID x 0.87" OD x 1.417"
- shock absorber
2шт.
42
A45056
STEP BOLT
BOLT - shoulder, shock absorber
1шт.
43
230-4216
LOCK NUT,3/8"-16, GA
NUT - hex lock, 3/8 inch NC
1шт.
A49654
ADJUSTER
ASSEMBLY - seat, Includes: Ref. 45 - 53
1шт.
45
A45481
HANDLE
GRIP - lever, plastic
1шт.
46
A45523
SLIDE
ASSEMBLY - seat mounting, left hand (With spring), Includes: Ref. 48
1шт.
47
A49653
SLIDE
ASSEMBLY - seat mounting, right hand (With spring and lever), Includes: Ref. 48
1шт.
48
L35503
SPRING
- return, slide
1шт.
49
S115782
BUSHING
SPACER - slide
4шт.
50
11-514
CARRIAGE BOLT,Short NK, 5/16"-18 x 7/8", G2
BOLT - round head, square neck, 5/16 NC x 7/8 inch
2шт.
50
A47171
CARRIAGE BOLT
BOLT - lower base
2шт.
51
131-351
LOCK NUT,5/16"-18, GA
NUT - hex lock, 5/16 inch NC
4шт.
52
A48182
ROD
- connecting, latch
1шт.
53
A48181
BASE
- lower
1шт.
55
131-205
LOCK NUT,5/16"-18
NUT - hex lock, 5/16 inch NC
4шт.
Выбрано товаров: 49
