Артикул
Название
Примечание
Количество
1
A181468
GRILLE
ASSEMBLY - upper (Red) (Includes 15 x Ref. No. 15)
1шт.
1
A145887
GUARD
GRILLE ASSEMBLY - upper (White) (Includes 11 x Ref. No. 15)
1шт.
2
A162560
SCREEN
- upper grille
1шт.
3
A147667
BRACKET
- upper grille screen
2шт.
4
A147030
SPACER
- grille screen
8шт.
5
131-1180
LOCK NUT,1/4"-20, GA
NUT, LOCK, 1/4"-20, GA
4шт.
6
131-1180
LOCK NUT,1/4"-20, GA
NUT, LOCK, 1/4"-20, GA
7шт.
7
495-21031
WASHER,1/4"
- flat, 5/16 x 47/64 x 1/16 inch
7шт.
10
A145886
HOOD
- upper (White)
1шт.
10
A181467
HOOD
- upper (Red)
1шт.
11
1289341C2
PANEL ASSY.
PANEL - hood, upper left (Red) (Includes 9 x Ref. No. 15) (Replaces A181463)
1шт.
11
A145622
PANEL
- hood, upper left (White) (Includes 9 x Ref. No. 15)
1шт.
12
1289342C2
PANEL ASSY.
PANEL - hood, upper right (Red) (Includes 9 x Ref. no. 15) (Replaces A181462)
1шт.
12
A145623
PANEL
- hood, upper right (White) (Includes 9 x Ref. No. 15)
1шт.
13
131-1180
LOCK NUT,1/4"-20, GA
NUT, LOCK, 1/4"-20, GA
18шт.
14
495-21031
WASHER,1/4"
- flat, 5/16 x 47/64 x 1/16 inch
18шт.
15
1968127C1
STUD
- mounting, 1/4 inch NC (Replaces A160247)
1шт.
15
1974428C1
STUD
- mounting, 1/4 inch NC, Serial Range: (Optional-1968127C1)
1шт.
20
1974411C1
PANEL
- decal (Replaces A145688)
2шт.
21
131-205
LOCK NUT,5/16"-18
NUT - hex elastic, 5/16 inch
20шт.
22
495-21038
WASHER,5/16"
(flat, 3/8 x 7/8 x 5/64") 5/16"
20шт.
25
A149299
SEAL PROTECTION
- upper hood
1шт.
26
NSS
NOT SOLD SEPARAT
SEAL - hood to grille, 41 inch (Cut from A162397)
1шт.
26
A162397
SEAL
- adhesive sided (50 foot bulk length)
1шт.
27
NSS
NOT SOLD SEPARAT
SEAL hood to side panel, 32 inch (Cut from A162398)
2шт.
27
A162398
SEAL
- adhesive sided (50 foot bulk length)
1шт.
29
A181437
EMBLEM CASE/IH
EMBLEM - front, CASE IH (Current production)
1шт.
30
321-4739
EMBLEM
- front, CASE (Early production)
1шт.
31
131-431
PUSH-ON NUT,Self, Threading, 1/4"
NUT - hex washer, self-threading, 1/4 inch
2шт.
32
A145989
FRAME
- hood, left
1шт.
32
A145988
FRAME
- hood, right
1шт.
1536056C1
EMBLEM CASE/IH
MEDALLION new
1шт.
15360800C1
NUT new, to hold medallion
1шт.
Выбрано товаров: 33
