Артикул
Название
Примечание
Количество
1
A181469
GRILLE
GRILL ASSEMBLY - lower (Red), Includes: Ref. 2
1шт.
1
A145888
GRILLE
GRILL ASSEMBLY - lower (White), Includes: Ref. 2
1шт.
2
1974428C1
STUD
- mounting (Replaces A160247)
6шт.
3
A162558
SCREEN
- lower grille
1шт.
4
A147028
BRACKET
ANGLE - grille support, right hand
1шт.
4
A147029
BRACKET
ANGLE - lower grille, left hand
1шт.
5
A147030
SPACER
- grille screen
12шт.
6
131-1180
LOCK NUT,1/4"-20, GA
NUT, LOCK, 1/4"-20, GA
6шт.
8
413-612
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5
4шт.
9
492-11038
LOCK WASHER,3/8"
4шт.
10
495-81147
WASHER,0.41" ID x 2" OD x 0.11" Thk
- flat, 13/32 x 2 x 3/16 inch
4шт.
12
A147283
BRACKET
- support, lower side panel
2шт.
13
256873
BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd
4шт.
15
A181465
PANEL
- side, lower (Red)
2шт.
15
A145788
PANEL
- side, lower (White)
2шт.
16
A149069
STRAP
- side panel, lower
2шт.
17
A160078
BOLT
- adjuster, panel support
4шт.
18
87016560
JAM NUT,Jam, 3/8"-16, G5
4шт.
19
261-5478
SELF-TAP SCREW,Cross Pan Hd, 1/4"-20 x 1/2"
SCREW - tapping, hex washer head, 1/4 NC x 1/2 inch
8шт.
20
A147282
SPOOL
- lock, lower side panel
4шт.
23
A149132
SEAL
- lower side panel
2шт.
24
NSS
NOT SOLD SEPARAT
SEAL - lower grill, 60 inch (Cut from A162397)
1шт.
24
A162397
SEAL
- ashesive sided, 50 feet
1шт.
25
A145934
SUPPORT
- front, hood and grille
1шт.
26
492-11038
LOCK WASHER,3/8"
10шт.
27
413-612
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5
4шт.
28
425-106
NUT,3/8"-16, Cl 5
8шт.
29
413-616
BOLT,Hex, 3/8" - 16 x 1", Gr 5
2шт.
Выбрано товаров: 28
