Запчасти Case IH 1896 (6-60) - REAR AXLE, HOUSING AND PLANETARY GEARS, 96 AND 102" LONG, 3-7/8 DIA. AXLE, TRANS. S/N 16265423 & AFT (06) - POWER TRAIN

1

26-1436

BOLT,Hex, 7/8" - 9 x 2-1/4", Gr 8

- hex, 7/8 NC x 2-1/4 inch, grade 8

2шт.

2

A63221

PLATE

- bearing lock

2шт.

3

A63220

PLATE

- retaining, rear axle

2шт.

4

A179761

SHAFT

- rear axle (96 inch standard axle) (Replaces A168156)

2шт.

4

A179760

SHAFT

- rear axle (102 inch long axle)

2шт.

6

A63216

ROLLER BEARING,89.98mm ID x 44mm W

CONE - bearing, outer

2шт.

7

A63214

CUP

- bearing, outer

2шт.

8

A50324

BEARING CUP

CUP - bearing, inner

2шт.

9

A34339

BEARING

CONE - bearing, inner

2шт.

10

A179939

CARRIER

- planetary gear

2шт.

11

A168244

PIN,41.94mm OD x 138.2mm L

- planetary gear (With 3/8 inch hole)

6шт.

12

138-2066

PIN,3/8" x 1 1/2", Coiled

6шт.

13

A67116

WASHER

- planetary gear

12шт.

15

A151972

ROLLER

BEARING - roller, planet gear

228шт.

16

A67117

SPACER

- bearing separator

6шт.

17

A179955

GEAR

- planetary, rear axle

6шт.

18

A179956

GEAR

- ring, planetary

2шт.

21

A179983

HOUSING

- rear axle

2шт.

22

A63218

OIL SEAL

- oil,rear axle

2шт.

23

26-1072

BOLT,Hex, 5/8" - 11 x 4-1/2", Gr 8

- hex, 5/8 NC x 4-1/2 inch, grade 8

24шт.

25

A64303

WASHER

- flat, hardened steel

24шт.

26

A34890

BUCKET TOOTH KEY

KEY - axle, 5/8 x 6 inch

2шт.

27

138-127

LOCK PIN,1/4" x 1/2", Slotted

PIN, 1/4" x 1/2", Slotted

2шт.

28

345-118

SEALANT

COMPOUND - gasket eliminator (Loctite 515)

1шт.
