Запчасти Case IH 1896 (4-074) - INSTRUMENT CLUSTER (04) - ELECTRICAL SYSTEMS

1

AR169152

REMAN-INSTR CLUSTER

CLUSTER ASSEMBLY - instrument (Remanufactured) (North America only), Includes: Ref. 2 - 8

1шт.

1

AC169152

CORE-CLUSTER, INSTR

RETURN NUMBER - cluster (Use this number when returning cluster for credit)

1шт.

1

A169152

CLUSTER

ASSEMBLY - instrument (New), Includes: Ref. 2 - 8

1шт.

2

A48886

BUZZER

ALARM - instrument cluster

1шт.

3

A48887

GAUGE

COUNTER - instrument cluster

1шт.

4

A48888

BULB

- instrument cluster

3шт.

5

A48889

LAMP SOCKET

SOCKET - cluster bulb

3шт.

6

A48890

GASKET

- instrument cluster

1шт.

7

NSS

NOT SOLD SEPARAT

BODY - cluster

1шт.

8

NSS

NOT SOLD SEPARAT

PLATE - face, cluster

1шт.

15

187-1333

SELF-TAP SCREW,Cross Pan Hd, #10 x 3/4"

SCREW - mounting, pan head, no. 10-16 x 3/4 inch

4шт.
