Запчасти Case IH 1566 (06-06) - COOLING, FAN AND FAN BELTS Cooling

1

69682C3

BLADE

ASSY, fan, 1566 tractors

1шт.

179848

BOLT,Hex, 3/8" - 16 x 2 1/4", Gr 5

3шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

3шт.

1

538097R1

FAN

BLADE ASSY, fan, 1568

1шт.

179839

BOLT,Hex, 3/8" - 16 x 1", Gr 5

6шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

6шт.

2

NOT USED IN THIS APPLICATION

1шт.

3

NOT USED IN THIS APPLICATION

1шт.

532746R1

BELT

Water pump & alternator, 1566

1шт.

236161R2

BELT,47.00" L

V-BELT , Water pump and alternator, 1568 47.00" L

1шт.
