Запчасти Case IH 1566 (02-04) - MISCELLANEOUS, PRODUCT GRAPHICS Accessories & Attachments / Miscellaneous

67724C92

DECAL

PACKAGE, product graphics, 1566 tractors, Consists of

1шт.

2754374R1

DECAL

AUXILIARY FUEL TANK FILLING

1шт.

539403R1

CAUTION DECAL

CAUTION INSTRUCTION

1шт.

68819C1

CAUTION DECAL

CAUTION INSTRUCTIONS

1шт.

538064R1

DECAL

CAUTION INSTRUCTIONS, custom cab

1шт.

538065R1

DECAL

CAUTION INSTRUCTION, deluxe cab

1шт.

2751019R1

DECAL

DELUXE VERTICAL ACTING SEAT ADJ

1шт.

2753934R1

PRODUCT GRAPHIC

DIESEL SYMBOL

2шт.

538241R1

DECAL

ETHER ASSIST

1шт.

2752918R2

DECAL

HYD FILTER INSTRUCTIONS

1шт.

537999R1

DECAL

HYD FILTER WARNING

1шт.

2754187R1

DECAL

HYDRAULIC SEAT ADJUSTING

1шт.

70571C1

DECAL

ROPS CAUTION INSTRUCTIONS

1шт.

135708C1

DECAL

INTERNATIONAL NAME

2шт.

2750839R1

DECAL

PRODUCT GRAPHIC, LIGHTING SWITCH

1шт.

2751830R2

DECAL

PARK LOCK

1шт.

70773C1

DECAL

SEAT BELT AND ROPS, caution

1шт.

538657R1

PROTECTOR

SHIELD, heat

1шт.

2753675R1

PRODUCT GRAPHIC

TURBO

2шт.

67779C1

DECAL

1566 FARMALL

2шт.

64553C2

PRODUCT GRAPHIC

CAUTION INSTRUCTIONS, IPTO

1шт.

67725C92

PACKAGE, product graphics, 1568 tractors, Consists of

1шт.

NSS

NOT SOLD SEPARAT

AUXILIARY FUEL TANK FILLING

1шт.

539403R1

CAUTION DECAL

CAUTION INSTRUCTION

1шт.

68819C1

CAUTION DECAL

CAUTION INSTRUCTIONS

1шт.

538064R1

DECAL

CAUTION INSTRUCTIONS, custom cab

1шт.

538065R1

DECAL

CAUTION INSTRUCTIONS, deluxe cab

1шт.

NSS

NOT SOLD SEPARAT

DELUXE VERTICAL ACTING SEAT ADJ

1шт.

NSS

NOT SOLD SEPARAT

DIESEL SYMBOL

2шт.

NSS

NOT SOLD SEPARAT

DRAIN

2шт.

NSS

NOT SOLD SEPARAT

ETHER ASSIST

1шт.

NSS

NOT SOLD SEPARAT

HYD FILTER INSTRUCTIONS

1шт.

NSS

NOT SOLD SEPARAT

HYD FILTER WARNING

1шт.

NSS

NOT SOLD SEPARAT

HYDRAULIC SEAT ADJUSTING

1шт.

NSS

NOT SOLD SEPARAT

IMPLEMENT CLEARING CHECK

1шт.

NSS

NOT SOLD SEPARAT

INTERNATIONAL NAME

2шт.

NSS

NOT SOLD SEPARAT

LIGHTING SWITCH

1шт.

NSS

NOT SOLD SEPARAT

PARK LOCK

1шт.

70773C1

DECAL

SEAT BELT AND ROPS, caution

1шт.

NSS

NOT SOLD SEPARAT

1568 FARMALL

2шт.

64553C1

DECAL

CAUTION INSTRUCTIONS, IPTO

1шт.

547494R92

DECAL

PACKAGE, IH trademark product graphics

1шт.

61908C1

DECAL

PRODUCT GRAPHIC, caution warning

1шт.

71724C91

DECAL

PACKAGE, product graphic stripes, 1566 tractor, Consists of, Start Serial: 11929

1шт.

71724C91

DECAL

PACKAGE, product graphic stripes, 1568 tractor, Consists of, Start Serial: 7945

1шт.

120273C1

DECAL

1566 MODEL DESIGNATION (NSS)

1шт.

120272C1

DECAL

1588 MODEL DESIGNATION (NSS)

1шт.

120280C1

DECAL

RIGHT HOOD STRIPE (NSS)

1шт.

120279C1

DECAL

LEFT HOOD STRIPE (NSS)

1шт.

120281C1

DECAL

RIGHT REAR HOOD, w/o cab (NSS)

1шт.

120282C1

DECAL

LEFT REAR HOOD, w/o cab (NSS)

1шт.

120283C1

DECAL

RIGHT REAR HOOD, w/cab (NSS)

1шт.

120284C1

DECAL

LEFT REAR HOOD, w/cab (NSS)

1шт.

120269C1

DECAL

RIGHT SIDE DOOR (NSS)

1шт.

120268C1

DECAL

LEFT SIDE DOOR (NSS)

1шт.

120267C1

DECAL

RIGHT SIDE PILLAR (NSS)

1шт.

120266C1

DECAL

LEFT SIDE PILLAR (NSS)

1шт.

120271C1

DECAL

RIGHT UPPER HOOD (NSS)

1шт.

120270C1

DECAL

LEFT UPPER HOOD (NSS)

1шт.

386683R95

GASKET

SET, chassis overhaul, Consists of

1шт.

380067R3

GASKET

CLUTCH HOUSING GASKET

1шт.

384078R1

GASKET

CLUTCH HOUSING BOTTOM COVER GASKET

1шт.

380112R1

GASKET

CLUTCH HOUSING COVER GASKET

1шт.

383330R1

GASKET

DRAFT CONTROL ADJ OPENING COVER GASKET

1шт.

385757R1

GASKET

DRIVE ATT OPENING COVER GASKET

1шт.

369860R1

GASKET,0.79mm Thk

FRONT WHEEL HUB GASKET

2шт.

23977DB

GASKET

FUEL TANK FILLER CAP GASKET

1шт.

381467R1

GASKET

INDEPENDENT PTO OPENING COVER GASKET

1шт.

382257R1

GASKET

OIL FILTER COVER GASKET

1шт.

382244R2

GASKET

PUMP OPENING COVER GASKET

1шт.

380225R1

GASKET

REAR AXLE CARRIER GASKET

2шт.

380264R2

GASKET

REAR FRAME COVER GASKET

1шт.

380315R1

GASKET

REAR FRAME FRONT COVER GASKET

1шт.

382416R1

GASKET

VALVE ADJ OPENING COVER GASKET

1шт.

386682R95

SEAL KIT

PACKAGE, chassis overhaul o-ring, Consists of

1шт.

352221R1

O-RING,0.103" Thk x 0.549" ID, -113, Cl 5, 75 Duro

9/16 x 3/4 x 3/32 cam pivot & selector drive

2шт.

252483R1

O-RING,-218, 70 Duro, 1.234" ID x .139" Thk

1-1/4 x 1-1/2 x 1/8 clutch housing suction tube

2шт.

264681R1

O-RING,0.139" Thk x 6.48" ID, -260, Cl 5, 75 Duro

6-1/2 x 6-3/4 x 1/8, rear axle cap seal

2шт.

381884R1

O-RING,0.103" Thk x 0.987" ID, -120, Cl 6, 90 Duro

1 x 1-3/16 x 3/32 cover to seat support small

3шт.

386868R1

O-RING, 1-1/8 x 1-5/16 x 3/32 cover to seat support

1шт.

384377R1

O-RING,0.103" Thk x 2.55" ID, -141, Cl 6, 90 Duro

2-5/16 x 2-1/2 x 3/32 cover to seat support large

1шт.

360610R1

O-RING,1.609" ID x 0.139" Width

1-5/8 x 1-7/8 x 1/8 hydraulic filter suction tube

1шт.

382997R1

O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro

1/2 x 5/8 x 1/16 park lock actuating shaft

1шт.

352221R1

O-RING,0.103" Thk x 0.549" ID, -113, Cl 5, 75 Duro

9/16 x 3/4 x 3/32 cam pivot shaft

1шт.

355966R1

O-RING,0.424" ID x 0.103" Width

7/16 x 5/8 x 3/32 reverse shift pivot arm shaft

1шт.

385744R1

SEALING RING

rear frame pressure port oil

2шт.

388306R1

RING,32.77mm ID x 39.12mm OD x 3.17mm Thk

SEAL, rear frame pressure port oil

1шт.

387926R2

RING

seal draft control port cover

2шт.

379181R1

O-RING,0.614" ID x 0.07" Width

5/8 x 3/4 x 1/16 rear frame cover shift shafts

2шт.

529133R1

RING

rear axle carrier cap sealing

2шт.

371418R91

PACKAGE

front wheel bearing overhaul, Consists of

2шт.

G15215

ROLLER BEARING

BEARING ASSY, front wheel inner cone

1шт.

619387R1

BEARING CUP

BEARING, front wheel inner cup

1шт.

618023R91

BEARING ASSY,34.93mm ID x 18.2mm W

BEARING ASSY, front wheel outer cone

1шт.

371898R1

BEARING, CUP

Front wheel outer

1шт.

369860R1

GASKET,0.79mm Thk

front wheel hub cap

1шт.

370254R91

OIL SEAL,57.02mm ID x 82.55mm OD x 6.86mm Thk

OIL SEAL, front wheel

1шт.

48703D

RETAINER

front wheel oil seal

1шт.

67726C91

STRIPPER PACKAGE

PACKAGE, power brake piston and axle carrier o-ring service, Consists of

1шт.

63864C91

CYLINDER

ASSY, hyd power steering

1шт.

71820C91

END

ball joint rod

1шт.

179847

BOLT,Hex, 3/8" - 16 x 2", Gr 5

5шт.

69981R1

LOCK NUT,3/8"-16, GB

NUT, 3/8 p/t lock type 5

1шт.

609836R1

WASHER

1.031 x 1.750 x .054

2шт.

425-1914

SLOTTED NUT,7/8"-14, G5, Thk

NUT, 6/8-NF pln slt-thick type 5

1шт.

103399

PIN,5/32" x 1 3/4"

Split (Cotter), 5/32" x 1 3/4"

1шт.

Q175

WASHER

1.031 x 1.750 x .042 pln

1шт.

71788C1

BUSHING,25.4mm ID x 28.6mm OD x 25.4mm L

center arm

1шт.

350818R1

O-RING,0.984" ID x 0.139" Width

1 x 1-1/4 x 1/8

2шт.

71421C1

WASHER

1.031 x 1.75 x .153

3шт.

2751660R1

DECAL

medallion, rear center of cab

1шт.
