Запчасти Case IH 1470 (014) - VALVE MECHANISM AND CAMSHAFT, (504BDT) DIESEL ENGINE (02) - ENGINE

1

A58655

ARM

Rocker (Nos. 1, 3 & 5 exhaust valves)

3шт.

2

A58656

ARM

Rocker (Nos. 2, 4 & 6 exhaust valves)

3шт.

3

A58654

ARM

Rocker (Intake valves)

6шт.

4

A21105

ADJUSTMENT SCREW,3/8" - 24 x 1 9/16"

Rocker arm

12шт.

5

25-156

JAM NUT,Jam, 3/8"-24, G5

Lock, adj. screw

12шт.

6

A57532

SHAFT

ASSY, Rocker arms

3шт.

7

A27877

SPRING

Rocker shaft

3шт.

8

A27878

WASHER

Rocker shaft ends, 29/32 x 1-5/16 x .028"

1шт.

9

B18206

SNAP RING,#87, Ext

Rocker shaft

6шт.

10

A58657

TUBE

Oil, rocker arms

3шт.

11

A27880

O-RING,0.07" Thk x 0.18" ID, -8, Cl 5, 75 Duro

Oil tube

3шт.

12

A61128

BRACKET

Rocker shaft (Aluminum)

6шт.

13

A27881

BRACKET

Rocker shaft (Steel)

6шт.

14

A60885

STUD

Bracket, 7/16" N.C. x 5-7/8"

6шт.

15

A58659

STUD

Bracket, 7/16" N.C. x 4-5/16"

6шт.

16

195-29

WASHER,7/16"

15/32 x 59/64" x 5/64" (Used w/A61128 brkt.)

12шт.

17

25-107

NUT,7/16"-14, G5

12шт.

18

A58596

ROD

ASSY, Push

12шт.

19

NSS

NOT SOLD SEPARAT

LIFTER - push rod (Order Ref. 38)

12шт.

24

NSS

NOT SOLD SEPARAT

VALVE - exhaust (Order Ref. 39)

6шт.

25

NSS

NOT SOLD SEPARAT

INSERT - exhaust valve seat (Order Ref. 40)

6шт.

26

NSS

NOT SOLD SEPARAT

GUIDE - intake & exhaust valves (Order Ref. 41)

6шт.

27

NSS

NOT SOLD SEPARAT

VALVE - intake (Order Ref. 42)

6шт.

28

NSS

NOT SOLD SEPARAT

INSERT - intake valve seat (Order Ref. 43)

6шт.

29

A58628

SEAL,8mm ID x 13.77mm OD x 2.16mm Thk

Valve stem

12шт.

30

A58623

SEAT

Valve springs

12шт.

31

NSS

NOT SOLD SEPARAT

SPRING - valves (Order Ref. 44)

12шт.

32

NSS

NOT SOLD SEPARAT

ROTO-CAP - exhaust valve (Order Ref. 45)

6шт.

33

NSS

NOT SOLD SEPARAT

RETAINER - intake valve (Order Ref. 46)

6шт.

34

NSS

NOT SOLD SEPARAT

LOCK - valve spring (Keepers) (Order Ref. 47)

24шт.

38

A21653

KIT

LIFTER - push rod (Set of 4)

3шт.

39

A41753

VALVE

KIT - exhaust (Set of 2)

3шт.

40

A41757

INSERT

KIT - exhaust valve (Set of 2)

3шт.

41

A41781

GUIDE

KIT - intake & exhaust valve (Set of 2)

6шт.

42

A41754

VALVE

KIT - intake (Set of 2)

3шт.

43

A42259

INSERT

KIT - intake valve (Set of 2)

3шт.

44

A42895

SPRING

KIT - valves (Set of 4)

3шт.

45

A57433

COIL

ROTO-CAP KIT - exhaust valve (Set of 2)

3шт.

46

A21657

LOCK

RETAINER KIT - intake valve (Set of 2 retainers & 4 locks)

3шт.

47

A40352

LOCK

KIT - valve keepers (Set of 8)

3шт.

50

A58591

CAMSHAFT

w/o fuel pump lobe

1шт.

51

A23544

BUSHING

KIT - camshaft, Includes: Ref. 52 - 54

1шт.

52

A23487

BUSHING,44.35mm ID x 60.3mm OD x 29.62mm L

BUSHING - rear, 15/32" wide

1шт.

53

A21019

BUSHING,57.05mm ID x 60.33mm OD x 36.63mm L

BUSHING - intermediate, 1-27/64" wide

3шт.

54

A21018

BUSHING,57.11mm ID x 60.33mm OD x 42.32mm L

BUSHING - front, 1-41/64" wide

1шт.

55

A21017

WASHER

Thrust, 2-1/4 x 3-1/4 x 1/8"

1шт.

56

A58592

GEAR

Camshaft timing

1шт.

57

A58593

GEAR

Idler drive

1шт.

58

126-29

WOODRUFF KEY,#C, 5/16" x 1 1/8"

Timing gear

1шт.

59

A58594

LOCK WASHER

Tab

1шт.

60

A58595

NUT

Timing gear retaining

1шт.

61

P0027853A

LARGE PIN

SPRING - thrust plunger

1шт.

62

A27852

PLUNGER

Thrust, camshaft

1шт.
