Запчасти Case IH 1470 (172) - FRAME AND ATTACHING PARTS (09) - CHASSIS

1

A12227

VALVE SPRING

SPRING - engine mount

1шт.

14-1472

BOLT - 7/8" x 4" N.F. hex.

1шт.

195-49

WASHER

- plain, 7/8"

1шт.

131-17

LOCK NUT

LOCKNUT - 7/8" N.F. hex.

1шт.

2

T38459

SUPPORT - engine, front

1шт.

13-1244

BOLT,Hex, 3/4" - 10 x 2-3/4", Gr 5

2шт.

92-12

LOCK WASHER,3/4"

WASHER, LOCK, 3/4"

2шт.

25-1012

NUT,3/4"-10, G5

2шт.

3

A55186

SUPPORT - transmission mounting, R.H.

1шт.

113-906

BOLT,Hex, 1" - 8 x 2-1/2", Gr 8, Full Thd

- 1" x 2-3/4" grade 8 Z.P. hex.

2шт.

131-20

LOCK NUT,1"-8, GB

LOCKNUT - 1" N.C. hex.

2шт.

113-800

BOLT - 7/8" x 3-3/4" grade 8 Z.P. hex.

2шт.

131-18

TUBE NUT,7/8"-9, GB

LOCKNUT - 7/8" N.C. hex.

2шт.

4

L10528

SUPPORT - transmission mounting L.H.

1шт.

113-906

BOLT,Hex, 1" - 8 x 2-1/2", Gr 8, Full Thd

- 1" x 2-3/4" grade 8 Z.P. hex.

2шт.

131-20

LOCK NUT,1"-8, GB

LOCKNUT - 1" N.C. hex.

2шт.

113-800

BOLT - 7/8" x 3-3/4" grade Z.P. hex.

2шт.

131-18

TUBE NUT,7/8"-9, GB

LOCKNUT - 7/8" N.C. hex.

2шт.

5

T38432

FRAME ASSEMBLY

1шт.

6

T38412

TRUNNION - front axle mounting, Includes: Ref. 7

1шт.

7

A12058

BUSHING,44.88mm ID x 53.92mm OD x 38.1mm L

- front axle trunnion mounting

2шт.

8

A14003

WASHER

- trunnion mounting pivot

2шт.

9

A14001

PIN - pivot, trunnion

2шт.

219-36

LUBE NIPPLE,45 Degree Elbow, 1/8" - 27 NPTF

FITTING - grease, 1/8" x 45 degrees

2шт.

10

A15157

LOCK ASSY

LOCK - pivot pin bolt

2шт.

13-816

BOLT,Hex, 1/2" - 13 x 1", Gr 5, Full Thd

4шт.

11

A56111

HOOK - towing

1шт.

13-1040

BOLT,Hex, 5/8" - 11 x 2-1/2", Gr 5

3шт.

92-10

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

3шт.

129-107

NUT,5/8"-11, G5

3шт.

12

T87899

WEIGHT - front (Machinery item)

1шт.

113-737

BOLT,Hex, 3/4" - 10 x 6", Gr 5

4шт.

195-109

WASHER,3/4"

- plain, 2" x 13/16" x #9 ga. Z.P.

8шт.

192-27

LOCK WASHER,3/4"

WASHER, LOCK, 3/4"

4шт.

129-108

NUT,3/4"-10, G5

4шт.

113-604

BOLT,Hex, 5/8" - 11 x 2", Gr 5

3шт.

192-25

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

3шт.

13-1040

BOLT,Hex, 5/8" - 11 x 2-1/2", Gr 5

3шт.

92-10

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

3шт.

129-107

NUT,5/8"-11, G5

3шт.

12

T87900

WEIGHT - front (Machinery item)

2шт.

113-735

BOLT,Hex, 3/4" - 10 x 9", Gr 5

- 3/4" x 9" N.C. hex. Z.P.

4шт.
