Запчасти Case IH 1256 (E-06) - FUEL SYSTEM, PRE-CLEANER, PRE-SCREENER (02) - FUEL SYSTEM

392039R91

CLEANER

PRE-CLEANER, pre-screener assy

1шт.

1

321262R91

MANIFOLD

PRE-CLEANER ASSY

1шт.

2

COVER ASSY, pre-cleaner, not serviced separately, order pre-cleaner assy, 321262R91

1шт.

3

277377R1

FILTER BOWL

BODY, pre-cleaner

1шт.

4

SLEEVE, pre-cleaner, not serviced separately, order pre-cleaner assy, 321262R91

1шт.

5

392637R91

BODY ASSY, pre-screener

1шт.

6

384543R91

SCREEN

W/TWO CLIPS & FOUR SPRINGS

1шт.

7

353639R1

VALVE SPRING

SPRING, screen lock tension

4шт.

8

353758R1

CLIP

screen lock spring

2шт.

9

20946R91

CLAMP ASSY, pre-screener

1шт.
