Артикул
Название
Примечание
Количество
374019R91
PARTS ACCESSORY, single front wheel
1шт.
1
350302R2
FORK, front bolster
1шт.
13452R1
BOLT, 1/2-13 x 3-1/2 sq-hd mach
2шт.
102637
NUT,1/2"-13, G5
2шт.
271611
BOLT,Hex, 3/4" - 10 x 2", Gr 5
SCREW, 3/4-10 x 2 hex-hd cap
4шт.
103323
LOCK WASHER,1/2"
WASHER, LOCK, 1/2"
2шт.
2
425-1520
JAM NUT,Jam, 1 1/4"-12, G5
1-1/4-12 hex. jam
2шт.
3
38916D
LOCK WASHER
front axle nut lock
24шт.
4
351419R11
PROTECTOR
SHIELD ASSY, front wheel hub short
1шт.
5
351417R11
AXLE ASSY, front wheel
1шт.
6
48539DA
PACKING RING
SEAL, front wheel oil
2шт.
7
ST2049
TAPERED BEARING,1.3755" ID x 2.718" OD x 0.7953"
BEARING ASSY, front wheel cone
2шт.
8
48548D
WASHER
front wheel oil seal
2шт.
9
ST974
TAPERED BEARING,1.313" ID x 2.718" OD x 0.7953"
BEARING, front wheel cup
2шт.
10
60288DA
BEARING CAP,1.4375" ID x 2.7125" OD x 0.40625"
front wheel brg grease
2шт.
11
351398R21
HUB ASSY, front wheel
1шт.
12
351397R92
WHEEL, guide 5.50F-20 for 7.50 x 20 tire, optional with 360133R92
1шт.
12
360133R92
WHEEL, guide 5.50F-20 for 7.50 x 20 tire, optional with 351397R92
1шт.
13
358134R1
BOLT (MACHINE),9/16" - 18 x 1 3/4"
BOLT, front wheel mounting
6шт.
14
351793R1
WHEEL NUT
NUT, front wheel mounting
6шт.
15
351416R11
SPACER ASSY, front wheel brg
1шт.
16
351418R1
BEARING LOCK NUT
front wheel brg adj
2шт.
17
351420R11
PROTECTOR
SHIELD ASSY, front wheel hub long
1шт.
Выбрано товаров: 23
