Артикул
Название
Примечание
Количество
1
529022R2
GEAR
differential bevel RH, 28T
1шт.
2
534524R92
CASE
ASSY, differential, composed of (12) bolt 55972DA, (1) case 406020R2 (NSS), (1) case 529024R2 (NSS), (1) gear 406021R1, (12) nut 381368R1
1шт.
3
391685R1
RETAINER, differential bearing RH, with seal
1шт.
3
68684C1
RETAINER
differential bearing RH, without seal
1шт.
4
ST2104
BEARING ASSY
RH roller cone
1шт.
5
ST986
TAPERED BEARING,133.35mm OD x 22.28mm W
BEARING, RH roller cup
1шт.
6
391689R91
OIL SEAL
SEAL, differential brg retainer RH, for retainer, 391685R1
1шт.
7
529025R1
SHAFT
bull pinion & brake LH
1шт.
8
529026R1
SHAFT
bull pinion & brake RH
1шт.
9
283375R91
NEEDLE BEARING
ASSY, needle
1шт.
10
529027R91
OIL SEAL
oil
1шт.
11
529028R1
HOUSING, RH brake
1шт.
24959R1
SCREW w/nylon pellet insert, 5/8-11 x 5-1/4 hex-hd cap
4шт.
NLS
NO LONGER SERVICED
SCREW, 5/8-11 x 3-3/4 hex-hd cap
2шт.
12
300026R1
RING
retaining
2шт.
13
529030R1
SHAFT
inner
1шт.
14
529031R1
DISC
ASSY, differential lock friction
1шт.
15
529032R1
SPRING
piston return
8шт.
16
529033R1
PLATE ASSY.
PLATE, pressure
1шт.
17
529401R11
HOUSING
ASSY, piston, composed of (1) housing 529029R1 (NSS), (1) housing 529401R1 (NSS), (2) pin 20027R1, (1) plug 9409954
1шт.
20027R1
PIN,5/16" x 1 1/4"
5/16 x 1-1/4 dowel
2шт.
9409954
PLUG,Hex Soc, 1/16"-27
1/16-27 auto soc-hd pipe
1шт.
138202
SCREW,1/4" - 20 x 1"
1/4-20 x 1 hex-soc-hd cap
6шт.
18
529404R91
SEAL
inlet shaft oil
1шт.
19
3046994R1
O-RING,0.139" Thk x 5.609" ID, -255, Cl 5, 75 Duro
5-5/8 x 5-7/8 x 1/8, piston outer
1шт.
20
252483R1
O-RING,-218, 70 Duro, 1.234" ID x .139" Thk
1-1/4 x 1-1/2 x 1/8, piston inner
1шт.
21
529034R1
PISTON ASSY.
PISTON, differential lock brake
1шт.
22
9410199
HYD CONNECTOR,3/8"-24, 37 Degree x 3/8"-24
UNION, 3/8-24 37 deg hyd flared tube short swivel
1шт.
23
379795R1
O-RING,0.064" Thk x 0.301" ID, -903, Cl 6, 90 Duro
3-1, .301" ID x .064" Thk
1шт.
24
529402R2
HYD TUBE
SHAFT ASSY, oil inlet
1шт.
25
529036R11
COVER ASSY, differential lock
1шт.
23112R1
PIN, 1/8 x 1/2 dowel 1/8" x 1/2"
1шт.
NLS
NO LONGER SERVICED
SCREW, 1/4-20 x 7/8 hex-hd cap
4шт.
103319
LOCK WASHER,1/4"
WASHER, LOCK, 1/4"
4шт.
26
65416C92
LOCK VALVE
VALVE ASSY, differential lock, replaces 529003R91, for components see list of parts under details of differential lock valve
1шт.
272393
PISTON,Hex, 3/8" - 16 x 6 1/4", Gr 5
SCREW, 3/8-16 x 6-1/4 hex-hd cap
1шт.
536642R1
WASHER
13/32 x 1 x .060
1шт.
27
535466R2
TUBE ASSY, reducing valve supply
1шт.
28
9410974
ELBOW,90 Degree, 7/16"-20, 37 Degree x 7/16"-20, O-Ring
7/16-20 37 deg C-Z hyd flared tube adj str thd 90 deg
1шт.
29
369751R1
O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro
3/8 x 1/2 x 1/16
3шт.
30
9410974
ELBOW,90 Degree, 7/16"-20, 37 Degree x 7/16"-20, O-Ring
7/16-20 37 deg C-Z hyd flared tube adj str thd 90 deg
1шт.
31
534750R92
VALVE
ASSY, pressure reducing, for components see list of parts under details of pressure reducing valve
1шт.
179814
SPACER
2шт.
32
535467R1
BRACKET, pressure reducing valve
1шт.
14995R1
BOLT
3/8-16 X 3/4 sq-nk crg
1шт.
102635
NUT,3/8"-16, G5
1шт.
33
534529R1
TUBE
ASSY, reducing valve to differential lock
1шт.
34
9411102
ELBOW,45 Degree, 7/16"-20, 37 Degree x 7/16"-20, O-Ring
7/16-20 37 deg C-Z hyd flared tube adj str thd 45 deg
1шт.
35
9410280
ELBOW,90 Degree, 9/16"-18, 37 Degree x 9/16"-18, 37 Degree Fem Sw
9/16-18 37 deg C-Z hyd flared tube 90 deg swivel
1шт.
36
535468R2
TUBE ASSY, pressure reducing valve
1шт.
37
535464R2
TUBE
ASSY, differential lock dump
1шт.
534250R1
HOSE
tube bumper
3шт.
38
120286C1
TEE
differential lock dump tube, replaces 529041R1
1шт.
39
9411117
TEE,9/16"-18, 37 Degree x 9/16"-18, O-Ring Br
9/16-18 37 deg C-Z hyd flared tube adj str thd
2шт.
40
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
6-1, 90 Duro, .468" ID x .078" Thk
2шт.
41
529042R1
SPACER
PEDAL
1шт.
42
384561R1
SNAP RING,#40, Ext
Ring, Snap, , pedal #40, Ext
1шт.
43
529043R1
PAD
pedal
1шт.
44
393071R2
BELLOWS
BOOT, pedal
1шт.
45
529044R1
LOCK WASHER
pedal boot
1шт.
46
369384R1
O-RING,0.072" Thk x 0.414" ID, -905, Cl 6, 90 Duro
5-1, 90 Duro, .414" ID x .072" Thk
1шт.
47
164596C1
ELBOW
9/16-18 C-Z deg hyd flared tube x 1/2-20 adj str thd 90 deg
1шт.
48
535465R2
TUBE ASSY, differential lock supply
1шт.
49
384891R11
CLAMP
STRIP ASSY, hyd tube clamp
1шт.
50
384891R1
CLAMP
STRIP, hyd tube clamp
1шт.
179796
BOLT,Hex, 1/4" - 20 x 7/8", Gr 5
SCREW, 1/4-20 x 7/8 hex-hd cap
1шт.
51
528163R1
TUBE
ASSY, brake pressure
1шт.
52
391814R11
SHIELD ASSY, bull pinion brg oil, 966, Serial Range: -15283
1шт.
52
391814R11
SHIELD ASSY, bull pinion brg oil, 1066, Serial Range: -19282
1шт.
423324
SCREW,Hex L/Wshr Hd, #10-24 x 7/16"
w/ext-tooth lock washer, 10-24 x 7/16 hex-hd mach
3шт.
53
536629R1
BUSHING,10.03mm ID x 19.81mm OD x 18.29mm L
platform isomount
1шт.
54
536678R1
SPACER, differential lock valve
1шт.
Выбрано товаров: 73
