Запчасти Case IH 1066 (08-30) - ELECTRICAL, CLIPS (06) - ELECTRICAL

Схема запчастей Case IH 1066 - (08-30) - ELECTRICAL, CLIPS (06) - ELECTRICAL
5
3
1
6
7
4
2

Артикул

Название

Примечание

Количество

1

370535R1

CLIP

5/8, 13/16, 1-1/64, 9/32 (I)

1шт.

1

362122R1

CLIP

3/4, 15/16, 1-7/8, 13/32 (I)

1шт.

1

536034R1

SPARE PART 3/4, 25/32, 1-3/4, 5/16 (I)

1шт.

88542

BOLT,Hex, 1/4"-20 x 1/2", Gr 5

1шт.

103319

LOCK WASHER,1/4"

1шт.

109084

NUT,1/4"-20, G5

1шт.

1

364408R1

SPARE PART 3/4, 1, 1-1/2, 13/32 (I)

1шт.

88574

BOLT,Hex, 5/16" - 18 x 1/2", Gr 5, Full Thd

5/16-18 x 1/2 hex. hd. cap

1шт.

95-11034

WASHER,1/4"

11/32 x 11/16 x .060

1шт.

9635082

NUT,5/16" - 18, Gr 5

1шт.

1

365584R1

CLIP

5/8, 13/16, 1-1/64, 13/32 (I)

1шт.

179835

BOLT,Hex, 3/8" - 16 x 5/8", Gr 5, Full Thd

1шт.

95-11041

WASHER,3/8"

(13/32 x 13/16 x .060)

1шт.

102635

NUT,3/8"-16, G5

1шт.

1

370383R1

CLIP

3/4, 15/16, 1-3/4, 15/32 (I)

1шт.

1

370821R1

CLIP,ELECTRICAL

3/4, 1-1/8, 1-3/16, 15/32 (I)

1шт.

179833

BOLT,Hex, 3/8" - 16 x 1/2", Gr 5, Full Thd

1шт.

103321

LOCK WASHER,3/8"

1шт.

102635

NUT,3/8"-16, G5

1шт.

1

406123R1

CLAMP

3/4, 1-7/8, 2-3/4, 13/32 (I)

1шт.

2

(Not used in this application)

1шт.

3

370205R1

SPARE PART 3/4, 3/4, 2-7/8, 13/32 (I)

1шт.

3

370740R1

CLAMP

3/4, 3/4, 3-3/16, 15/32 (I)

1шт.

3

363660R1

CLIP

3/4, 3/4, 2-5/8, 13/32 (I)

1шт.

3

370820R1

CLIP

3/4, 3/4, 2-5/8, 17/32 (I)

1шт.

88574

BOLT,Hex, 5/16" - 18 x 1/2", Gr 5, Full Thd

5/16-18 x 1/2 hex. hd. cap

1шт.

95-11034

WASHER,1/4"

11/32 x 11/16 x .060

1шт.

9635082

NUT,5/16" - 18, Gr 5

1шт.

4

(Not used in this application)

1шт.

5

362666R1

CLIP

3/4, 2-1/2, 15/32 (I)

1шт.

6

384554R1

CLIP

3/4, 1-35/64, 13/32 (I)

1шт.

362127R1

CLIP

3/4, 1-1/4, 13/32 (I)

1шт.

179833

BOLT,Hex, 3/8" - 16 x 1/2", Gr 5, Full Thd

1шт.

103321

LOCK WASHER,3/8"

1шт.

6

384557R1

CLIP

3/4, 1-5/8, 9/32 (I)

1шт.

179789

BOLT,Hex, 1/4" - 20 x 3/8", Gr 5, Full Thd

1шт.

103319

LOCK WASHER,1/4"

1шт.

6

362123R1

CLIP

3/4, 2-1/8, 15/32 (I)

1шт.

88574

BOLT,Hex, 5/16" - 18 x 1/2", Gr 5, Full Thd

5/16-18 x /2 hex/ hd. cap

1шт.

103320

LOCK WASHER,5/16"

1шт.

9635082

NUT,5/16" - 18, Gr 5

1шт.

6

362120R1

CLAMP,9.53mm ID, 10.32mm Bolt Hole, P Type

3/4, 1-9/16,13/32 (I)

1шт.

6

670043C1

CLIP

3/4, 1-5/8, 13/32 (I)

1шт.

6

362667R1

CLIP

3/4, 1-61/64, 15/32 (I)

1шт.

179833

BOLT,Hex, 3/8" - 16 x 1/2", Gr 5, Full Thd

1шт.

103321

LOCK WASHER,3/8"

1шт.

6

388922R2

CLIP

3/4, 3-3/64, 3/8 (I)

1шт.

6

362126R1

CLIP

3/4, 3-5/8, 13/32 (I)

1шт.

6

363117R1

CLIP

1, 1-13/16, 9/32 (I)

1шт.

179789

BOLT,Hex, 1/4" - 20 x 3/8", Gr 5, Full Thd

1шт.

103319

LOCK WASHER,1/4"

1шт.

6

362666R1

CLIP

3/4, 2, 15/32 (I)

1шт.

6

384558R1

CLIP

1, 1-13/16, 21/32 (I)

1шт.

11002VA

WASHER

17/32 x 7/8 x 16 ga.

1шт.

179875

BOLT,Hex, 1/2" - 13 x 1/2", Gr 5

1/2-13 x 1/2 hex. hd. cap

1шт.

6

358986R1

CABLE CLIP

1, 1-15/16, 17/32 (I)

1шт.

6

383622R1

CLIP

1, 1-15/16, 22/32 (I)

1шт.

7

384556R1

CLAMP

3/4, 1, 1-61/64, 15/32 (I)

1шт.

Выбрано товаров: 58
