Запчасти Case IH OPTUM 270 CVT (37.162.010) - VAR - 758768, 758769, 758770, 758771, 758772, 758773, 759086, 759304, 759305, 759306, 759307, 759308 - FRONT, 3 POINT HITCH, SUPPORT (37) - HITCHES, DRAWBARS & IMPLEMENT COUPLINGS
№
Артикул
Название
Примечание
Количество
1
47557009
CARRIER
FHPL Carrier
1шт.
2
47658815
COVER ASSY
ASSY, Incl 24 - 27, Serial Range: -C7492
1шт.
2
48062388
COVER
ASSY, Incl 24 - 27, Start Serial: D7492
1шт.
3
47763829
BUSHING,50mm ID x 55mm OD x 48mm L
2шт.
4
47636333
SPACER,50.5mm ID x 76.5mm OD x 3mm L
2шт.
5
47457860
PIN,31.5mm OD x 128mm L
1шт.
6
837-20040
DOWEL,M20 x 40
2шт.
7
47658705
STUD,M20 x 2.5 x 185mm L
2шт.
8
86981465
FLANGE NUT,Hex, M20 x 2.5
2шт.
9
47671174
SCREW,Hex, M22 x 1.5 x 75mm L
4шт.
10
120103
BOLT,M8 x 1.25 x 16mm, Cl 8.8
4шт.
11
47634857
SLEEVE,18mm ID x 20mm OD x 20mm L, flangeOD 26mm
1шт.
12
47810734
PLATE
1шт.
Less Front ISOBUS
1шт.
13
47812641
BRACKET
1шт.
Less Front PTO Switch
1шт.
14
14304221
HEX SOC SCREW,M5 x 16mm, Cl 8.8, Full Thd
6шт.
15
87698783
WASHER,5.3mm ID x 8.9mm OD x 1.2mm Thk
6шт.
16
14305221
HEX SOC SCREW,M6 x 16mm, Full Thd, Cl 8.8
4шт.
17
86588450
WASHER,6.6mm ID x 12mm OD x 1.6mm Thk
4шт.
19
47812643
PLATE
2шт.
Less Front Sockets
1шт.
20
87643929
PLATE
1шт.
Less External Front HPL Switch
1шт.
21
10902124
SCREW,Hex, M6 x 14mm, Cl 8.8
2шт.
22
85700614
DUST CAP,0.532", 0.750" OD, 0.437" D
4шт.
23
718062034
DIA KIT, TRACTOR
Front Hydraulic Power Lift, Incl 1 - 21
1шт.
To See Full DIA KIT Composition Look for all the Figures Where the DIA KIT P/N Is Shown
1шт.
23
731033014
DIA KIT, TRACTOR
Front Hydraulic Power Lift, Incl 1 - 21
1шт.
To See Full DIA KIT Composition Look for all the Figures Where the DIA KIT P/N Is Shown
1шт.
24
47658806
RING
4шт.
25
47660521
RING
2шт.
26
48062354
SEAL,545mm x 25mm x 3mm
, Start Serial: D7492
1шт.
26
87315614
SEAL,545mm x 25mm x 10mm
, Serial Range: -C7492
1шт.
27
NSS
NOT SOLD SEPARAT
Cover, Incl in 2
1шт.
Выбрано товаров: 36
