Запчасти Case IH OPTUM 270 CVT (33.350.100) - VAR - 758802, 758803, 758804, 758805, 758806, 758807, 758871 - ANTILOCK BRAKING SYSTEM (ABS), PEDAL (33) - BRAKES & CONTROLS

1

47452015

BRACKET

ASSY, Incl 2 - 5

1шт.

2

NSS

NOT SOLD SEPARAT

Bracket, Incl in 1

1шт.

3

83963569

CAPTIVE WASHER SCREW,Pan Hd, M4 x 12mm, Cl 4.8

4шт.

4

84582018

BRACKET

2шт.

5

86610170

LOCK PIN,M4 x 12, Slotted

6шт.

6

84598289

BRACKET

1шт.

7

16043424

SCREW,Hex, M8 x 1.25 x 20mm, Cl 8.8, Full Thd

4шт.

8

12601379

WAVE WASHER,Wave, M8.4

4шт.

9

82025747

RUBBER PEDAL PAD

2шт.

10

84566074

PEDAL

ASSY, Black, Incl 9 (Qty 1), 11, 12 (Qty 2), 13

1шт.

11

NSS

NOT SOLD SEPARAT

LH Pedal, Incl in 10

1шт.

12

14307521

HEX SOC SCREW,M10 x 1.25 x 30mm, Cl 8.8, Full Thd

4шт.

13

84406177

BUSHING,42mm ID x 48mm OD x 48mm W

1шт.

14

84566075

PEDAL

ASSY, Black, Incl 9 (Qty 1), 12 (Qty 2), 15, 16

1шт.

15

NSS

NOT SOLD SEPARAT

RH Pedal, Incl in 14

1шт.

16

84524219

BUSHING,42mm ID x 52mm OD x 60mm L

1шт.

17

84406167

LEVER

Black

1шт.

18

84209162

PIN,11.965mm OD x 70mm L

1шт.

19

84525174

BUSHING,25mm ID x 31mm OD x 64mm L

2шт.

20

11088180

CIRCLIP,M11, Stainless

1шт.

21

84529389

PIN,25mm OD x 353mm L

1шт.

22

10902021

BOLT,Hex, M6 x 12mm, Cl 8.8

1шт.

23

47544008

SHAFT,10mm ID x 15mm OD x 44mm L

1шт.

24

47415837

BAR

1шт.

25

87310426

SPACER,32mm ID x 38mm OD x 134mm L

1шт.

26

83937363

SNAP RING

1шт.

27

47396618

SPRING,36mm OD x 139mm L

2шт.

28

84406195

SPRING,20mm OD x 138mm L

1шт.

29

82027074

SPACER,20mm ID x 30mm OD x 25mm L

6шт.

30

14496601

WASHER,10.5mm ID x 21mm OD x 2mm Thk

6шт.

31

11107321

BOLT,Hex, M10 x 55mm, Cl 8.8

4шт.

32

11701711

NUT,Hex, M10, Cl 8, ZND

2шт.

33

10615479

LOCK WASHER,6.4mm ID x 11mm OD x 0.7mm Thk

1шт.

34

11088071

CIRCLIP,M10

1шт.
