Запчасти Case IH MXU135 (1.97.0) - CONTROL ELECTRONIC LIFT (10) - OPERATORS PLATFORM/CAB

1

82028279

CONTROL

L/HTS-L/Slip Switch, Serial Range: -C5228

1шт.

2

14496301

WASHER,5.3mm ID x 10mm OD x 1mm Thk

2шт.

3

16043024

SCREW,Hex, M8 x 1.25 x 12mm, Cl 8.8, Full Thd

2шт.

4

12646704

WASHER,8.15mm ID x 20mm OD x 2mm Thk

2шт.

5

47056366

COVER

1шт.

6

81862738

PLUG,M38 x 28 x 5mm

28MM

3шт.

7

47057509

FASTENER

2шт.

8

14499401

WASHER,8.4mm ID x 14mm OD x 1.6mm Thk

1шт.

9

87543715

POTENTIOMETER,4000 Ohm, 13.5 VDC

Rotary Position Sensor

1шт.

10

5188968

ROD

1шт.

11

89821714

CLIP

2шт.

12

86544168

BOLT,Hex, M5 x 35mm, Cl 8.8

2шт.

13

87631740

LEVER

1шт.

14

11087976

CIRCLIP,Ext., M8, BLO

1шт.

15

87356781

ARMREST ASSY.

L/Slip, Serial Range: D5228-C5321

1шт.

16

87398439

ARMREST ASSY.

, Start Serial: D5321

1шт.
