Артикул
Название
Примечание
Количество
1
87303619
HYDRAULIC VALVE
1шт.
2
47123211
HYD VALVE SECTION
, Serial Range: -C5500
2шт.
2
87396804
VALVE SECTION
, Start Serial: D5500
2шт.
3
5150104
STUD,3/8" - 24 x 5"
3шт.
4
87303247
END PLATE
, Serial Range: -C5500
1шт.
4
87396840
END PLATE
, Start Serial: D5500
1шт.
5
10569474
LOCK WASHER,10.2mm ID x 16mm ID x 2.5mm Thk
M10, Serial Range: -C5500
3шт.
5
12648304
WASHER,10.2mm ID x 17mm OD x 1.5mm Thk
, Start Serial: D5500
3шт.
6
47123263
CONTROL LEVER
, Serial Range: -C5311
2шт.
7
87559221
MANIFOLD VALVE
Upper
1шт.
8
87559220
MANIFOLD VALVE
Central
1шт.
9
47135700
BANJO BOLT
2шт.
10
47136004
BANJO BOLT
2шт.
11
5179558
COUPLING, QUICK, FEM,Hex, M22 x 1.5 x 110.8mm L
Incl. 17, include p/n 1534623C1
4шт.
1534623C1
SEAL KIT
1шт.
12
47127567
SUPPORT
to include p/n 1534623
1шт.
13
15970524
BOLT,Hex, M10 x 1.25 x 20mm, Cl 8.8, Full Thd
2шт.
14
14457480
O-RING,18.72mm ID x 2.62mm Thk , -116, Cl 5
4шт.
15
4958830
BACK-UP RING,16.26mm ID x 20.62mm OD x 1.14mm Thk
4шт.
16
14457281
O-RING,0.612" ID x 0.103" Width
2шт.
17
14438085
O-RING,19.3mm ID x 2.4mm
6шт.
18
14437985
O-RING,15.3mm ID x 2.4mm
2шт.
19
5146467
RING,19.2mm ID x 20.2mm OD x 2.3mm Thk
, Serial Range: -C5500
3шт.
20
5146468
O-RING,0.103" Thk x 0.549" ID, -113, Cl 5, 75 Duro
, Serial Range: -C5500
3шт.
21
5146466
RING,24mm ID x 25mm OD x 2.3mm Thk
, Serial Range: -C5500
3шт.
22
5135739
O-RING,0.737" ID x 0.943" OD x 0.103"
, Serial Range: -C5500
9шт.
23
5180283
RING,16mm ID x 18.5mm OD x 2.1mm Thk
, Serial Range: -C5500
9шт.
24
5116857
NUT,3/8" - 24
3шт.
25
5116896
LINK,19.05mm Pitch
, Serial Range: -C5776
2шт.
25
87658153
LINK,19.05mm Pitch
, Start Serial: D5776
2шт.
26
5172456
PIN,6mm OD x 20mm L
2шт.
28
47125148
HYD CONNECTOR
Includes Ref.29, 30
1шт.
29
14438085
O-RING,19.3mm ID x 2.4mm
1шт.
30
14453581
O-RING,0.07" Thk x 0.739" ID, -18, Cl 7, 75 Duro
1шт.
31
47123080
MANIFOLD VALVE
1шт.
32
87393956
CONTROL LEVER
, Start Serial: D5311
2шт.
33
87335172
SEALING RING,19mm ID x 26mm OD x 3mm Thk
SEALRING 19 x 3.50 x 3, Start Serial: D5500
9шт.
34
87357854
SEALING RING,15.5mm ID x 19.5mm OD x 2mm Thk
SEALRING, Start Serial: D5500
3шт.
