Запчасти Case IH MXU115 (1.32.6/01) - (VAR.160) DIFFERENTIAL LOCK FOR STRENGTHENED WHEEL AXLE - DIFFERENTIAL LOCKS (03) - TRANSMISSION

Схема запчастей Case IH MXU115 - (1.32.6/01) - (VAR.160) DIFFERENTIAL LOCK FOR STRENGTHENED WHEEL AXLE - DIFFERENTIAL LOCKS (03) - TRANSMISSION
1
5
6
2
4
3

Артикул

Название

Примечание

Количество

1

5191926

PISTON

1шт.

2

14461981

O-RING,5.487" ID x 0.103" Width

2,62X139,4

1шт.

3

14462681

O-RING,7.237" ID x 0.103" Width

1шт.

4

5191924

CLUTCH PLATE

6шт.

5

5191925

CLUTCH DRIVING PLATE

6шт.

6

5191927

SEALING RING,67mm ID x 75mm OD x 2.60mm

2шт.

Выбрано товаров: 6
