Запчасти Case IH MXU110 (1.82.7/47[02]) - (VAR.013) 3 REMOTES(1NC+2CONFIG) FOR CCLS PUMP FOR MDC AND RELEVANT PARTS (07) - HYDRAULIC SYSTEM

1

87311424

CONTROL VALVE

1шт.

2

5195169

NUT,M8

3шт.

3

5195168

TIE-ROD,M8

3шт.

4

5192188

BODY

1шт.

5

87546169

CONTROL VALVE

1шт.

87546169R

REMAN-HYD VALVE

MXU100, MXU115, MXU125 all (7/03-)

1шт.

87546169C

CORE-VALVE HYD

Return Number

1шт.

6

87328572

HYD VALVE SECTION

2шт.

87328572R

REMAN-HYD VALVE

MXU100, MXU115, MXU125, ALL (7/03-)

2шт.

87328572C

CORE-VALVE HYD

Return Number

1шт.

7

47123063

QUICK MALE COUPLING

, Serial Range: -C5279

1шт.

7

87381964

QUICK MALE COUPLING

, Start Serial: D5279

1шт.

8

47123061

QUICK MALE COUPLING

, Serial Range: -C5279

1шт.

8

87381963

QUICK MALE COUPLING

, Start Serial: D5279

1шт.

9

47123059

QUICK MALE COUPLING

, Serial Range: -C5279

1шт.

9

87381958

QUICK MALE COUPLING

, Start Serial: D5279

1шт.

10

47129474

HEX SOC SCREW,M6 x 35mm

8шт.

11

87730706

CONTROL VALVE

1шт.

87730706R

REMAN-HYD VALVE

MXU100, MXU115, MXU125 ALL CASE IH TRACTOR (7/03-)

1шт.

87730706C

CORE-VALVE HYD

RETURN NUMBER

1шт.

12

47129475

HEX SOC SCREW,M6 x 50mm

8шт.

13

5191704

CHECK VALVE

Incl. 14

1шт.

14

5191705

O-RING,9.4mm D x 2.1mm Thk

1шт.
