Запчасти Case IH MXU110 (1.32.8[01]) - PUMPS FOR HYDRAULIC SYSTEM AND LIFT (03) - TRANSMISSION

1

14471380

O-RING,0.21" Thk x 2.1" ID, -330, Cl 5, 75 Duro

1шт.

2

47128297

TUBE

1шт.

3

47128257

BOLT

1шт.

4

14464481

O-RING,0.139" Thk x 1.984" ID, -226, Cl 7, 75 Duro

2шт.

5

47123333

SUPPORT

1шт.

6

10119040

PLUG,M27 x 2 x 20, Brass

1шт.

7

14438185

O-RING,24mm ID x 3mm

1шт.

8

5153030

BLEED SCREW,Bleeder, Hex, M8 x 1.25 x 25mm

1шт.

9

47129062

PLATE

1шт.

10

12164714

NUT,M10 x 1.25, Cl 8

3шт.

11

13449521

STUD

M10X15X22

3шт.

12

82025340

RESTRICTION SWITCH

Vacuum, Serial Range: -C5240

1шт.

13

5192915

FITTING

1шт.

14

47135287

HYDRAULIC OIL FILTER

1шт.

15

16044524

SCREW,Hex, M8 x 1.25 x 65mm, Cl 8.8

4шт.

16

14464280

O-RING,0.139" Thk x 1.734" ID, -224, Cl 5, 75 Duro

2шт.

17

47129011

FLANGE

1шт.

18

81864650

SWITCH ASSY

Oil Temp. Warning

1шт.

19

14306321

HEX SOC SCREW,M8 x 20mm, Cl 8.8

1шт.

20

5199024

SUPPORT

1шт.

21

5199025

TUBE

1шт.

22

14458281

O-RING,1.237" ID x 1.443" OD x 0.103"

1шт.

23

87303771

PRESSURE SWITCH

Vacuum, Start Serial: D5240

1шт.
